Taylor C844 Service Manual

173
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C844
-75
QTY.
C842
-78
QTY.
C842
-75
QTY.
C842
-60
QTY.
C842
-23
QTY.
C834
-75
QTY.
C832
-75
QTY.
C832
-28
QTY.
C832
-23
PART
NUMBER
HOOK-SHEET M32/35 LEFT 074184 2 2 2 2 103
HOOK-SHEET M32/35 RIGHT 074185 2 2 2 2 103
KIT A.-3FT RESTRAIN CABLE 074948 1 1 1 1 1 1 1 1 1 103
KIT A.-ACCESSORY *M832/835* X73142-SER 1 1 1 1 103 KIT NLA-ORDER SEPARATE
PCS AS NEEDED
CLIP-RELEASE MATERIAL-W/TAB 072673 8 8 8 8 000
SCREW-10-32X3/8 SLTD TRUSS 024298 9 9 9 9 000
SCREW-3/8-16X1 HEX HEAD CAP 001082 2 2 2 2 000
WASHER-3/8 USS FLAT CR3 000653 2 2 2 2 000
KIT A.-ACCESSORY X72886-SER 1 1 1 1 1 000 KIT NLA-ORDER SEPARATE
PCS AS NEEDED
CLIP-RELEASE MATERIAL-W/TAB 072673 9 9 9 9 6 000
ROD-RELEASE MAT. *842* REAR 073338 3 3 3 3 000
SCREW-10-32X3/8 SLTD TRUSS 024298 9 9 9 9 000
SCREW-3/8-16X1 HEX HEAD CAP 001082 2 2 2 2 000
WASHER-3/8 USS FLAT CR3 000653 2 2 2 2 000
KIT A.-GREASE SHIELD* X78330-SER 2 2 2 2 3 3 3 3 3 000
KIT A.-MOTOR X73998-SER 6 6 6 6 9 9 9 9 9 103 S/N M1103365 &
UP-REPLACES 072454
KIT A.-TUNE UP *C832/834/835* X83114-2 X X X X 000 REPLACES X74514-11
KIT A.-TUNE UP *C842/844/845* X83114-3 X X X X X 000 REPLACES X74514-10
LABEL-CONTROL PANEL-INTL 075699-SYM 1 1 2 000
LABEL-CONTROL PANEL-INTL SYMBL 075699SYM3 1 1 1 000
LABEL-ELEC-CAUTION 075484 1 1 1 1 1 1 1 1 1 000
LABEL-EQUIPOTENTIAL CONNECTOR 076406 1 1 1 1 1 2 2 1 2 000 CONTROL BOX
LABEL-GROUNDING SYMBOL 017669 1 000
LABEL-OPERATION*C842/C844* 072865 1 1 1 1 1 1 1 1 1 000
LABEL-WARN GRILL MCD AUTH SVC 072658 3 3 3 3 3 3 3 000
LABEL-WARN-GRILL-MCD-SVC- 072658-CAN 3 000
LABEL-WARN-GRILL-MCD-SVC-P/G 072658-PG 3 000
LABEL-WARRANTY-MCD 056691 1 1 1 1 1 1 1 1 1 000
MAN-OPER C832/C834 073193-M 1 1 1 1 000
MAN-OPER C842 MCDONALD'S 072768-M 1 1 1 1 1 000
MANIFOLD A.-*C832* - AIR COMPRESSOR 073129 1 1 1 1 103
BLOCK MANIFOLD .030 ORFICE 073129-7 1 1 1 1 103
CONNECTOR-MATE LOCK 4 CIR-PIN 500534 1 1 1 1 103
