Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
174
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C844
-75
QTY.
C842
-78
QTY.
C842
-75
QTY.
C842
-60
QTY.
C842
-23
QTY.
C834
-75
QTY.
C832
-75
QTY.
C832
-28
QTY.
C832
-23
PART
NUMBER
FITTING-DIFFUSER 1/4 MPT 072695-8 1 1 1 1 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-5 2 2 2 2 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-6 1 1 1 1 103
GAUGE-130 PSI 1/8 MPT BACK M 072695-3 1 1 1 1 103
PIN-.084 OD/14-20 AWG-STRIP 021624 4 4 4 4 103
REGULATOR-PRESSURE 0-120 PSI 072695-2 1 1 1 1 103
SCREW-M3X0.5 072695-10 4 4 4 4 000
VALVE-PRESSURE RELIEF 70 PSI 072695-4 1 1 1 1 103
VALVE-SOLENOID 3 WAY 12 VDC 072695-1 2 2 2 2 103
MANIFOLD A.-C842/C844 072695 1 1 1 1 1 103 AIR COMPRESSOR
CONNECTOR-MATE LOCK 6 CIR-PI 028594 1 1 1 1 1 103
FITTING-DIFFUSER 1/4 MPT 072695-8 1 1 1 1 1 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-5 3 3 3 3 3 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-6 1 1 1 1 1 103
GAUGE-130 PSI 1/8 MPT BACK M 072695-3 1 1 1 1 1 103
PIN-.084 OD/14-20 AWG-STRIP 021624 6 6 6 6 6 103
PLUG-1/8 MP-NICKEL PLATED 020988 1 1 1 1 1 103
REGULATOR-PRESSURE 0-120 PSI 072695-2 1 1 1 1 1 103
SCREW-M3X0.5 072695-10 6 6 6 6 6 000
VALVE-PRESSURE RELIEF 70 PSI 072695-4 1 1 1 1 1 103
VALVE-SOLENOID 3 WAY 12 VDC 072695-1 3 3 3 3 3 103
MODULE-PROGRAM *C842* X72760-SER 4 4 4 4 000
MOTOR-24VDC *C832/C842*- NLA 072454 * * * * * * * * * 103 NA-USE X73998-SER KIT A
KIT A.-MOTOR X73998-SER 6 6 6 6 9 9 9 9 9 103 S/N M1103365 &
UP-REPLACES 072454
+SCREW-10-32X1-5/8 SOC. HD CAP 079117 24 24 24 24 36 36 36 36 36 000
+WASHER-#10 EXT. TOOTH LOCK 002681 24 24 24 24 36 36 36 36 36 000
+WASHER-#10 FLAT 18-8 SS 037841 24 24 24 24 36 36 36 36 36 000
O-RING-1-3/16OD X .103W 052733-120 8 8 8 8 12 12 12 12 12 000 REAR PLATEN ARM
O-RING-1-1/16OD X .103W 052733-118 4 4 4 4 6 6 6 6 6 000
PANEL A.-BACK PNL X72958-SER 1 1 1 1 103 S/N K8102227 & UP
PANEL A.-BACK SERVICE X72951 1 1 1 1 1 1 1 1 1 103 C842 S/N K8102227 & UP
REPLACES X78472
PANEL A.-BACK SERVICE X78472 1 1 103 S/N K8102226 & PRIOR
PANEL A.-BACK TWO SPEED FAN X74083-SER 1 103 S/N K8102226 & PRIOR
PANEL A.-CENTER-SHROUD X73331 1 1 1 1 103
