Taylor C844 Service Manual

175
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C844
-75
QTY.
C842
-78
QTY.
C842
-75
QTY.
C842
-60
QTY.
C842
-23
QTY.
C834
-75
QTY.
C832
-75
QTY.
C832
-28
QTY.
C832
-23
PART
NUMBER
PANEL A.-LIGHT *M25* X78845 1 1 1 1 103
PANEL A.-LIGHT X72434 1 1 1 1 1 103 CONTROL A.-SWITCH
PANEL A.-SIDE UPPER LT X72962 1 1 1 1 1 1 1 103 S/N K8102227 & UP
PANEL A.-SIDE UPPER RT X72965 1 1 1 1 1 1 1 103 S/N K8102227 & UP
PANEL A.-SIDE UPPER *M34* LT X74126 1 103
PANEL A.-SIDE UPPER *M34* RT X74127 1 103
PANEL A.-SIDE UPPER*C844* LT X72786 1 103 5/02/08 TO 99/99/99
PANEL A.-SIDE UPPER*C844* RT X72788 1 103 5/02/08 TO 99/99/99
PANEL-BACK TW0 SPEED FAN 072959 1 1 1 1 1 1 1 103 8/01/08 REPLACES 074085
PANEL-BACK TW0 SPEED FAN 074085 1 103 SERIES 92 *FRANCE*
C84275GR65 C84475GR65
PANEL-SIDE LEFT 072967 1 1 1 1 103 S/N K8102227 & UP
PANEL-SIDE RIGHT 072968 1 1 1 1 103 S/N K8102227 & UP
PANEL-SIDE *M 34*LEFT 074110 1 103
PANEL-SIDE *M 34*RIGHT 074111 1 103
PANEL-SIDE *C844* LEFT 072790 1 103 5/02/08 TO 99/99/99
PANEL-SIDE *C844* RIGHT 072791 1 103 5/02/08 TO 99/99/99
PCB A.-INTERF MTR *C832/C842* X73633-SER 2 2 2 2 3 3 3 3 3 MOTOR A.-MOUNT
PCB A.-INTERF MTR *C832/C842* X72701-SER 2 2 2 2 3 3 3 3 3 212 CONTROL
+SCREW-6-32X5/8 SLTD ROUND 019309 4 4 4 4 18 18 18 18 6 000
PLATEN A.-3100W SERV -WRAP X73333-23 2 212
PLATEN A.-3100W SERV*C832/C835-WRAP X73333-75 2 2 2 212
PLATEN A.-2600W 208V SERV *STANDARD X73182-23 3 212
PLATEN A.-2600W SERV WA *C842-WRAP X73598-23 3 212
PLATEN A.-2600W 220V SERV -STANDARD X73182-21 3 3 212
PLATEN A.-2450W 230V SERV -STANDARD X73183-75 3 3 212 STANDARD
PLATEN A.-2450W SERV WA C842-WRAP X73599-75 3 3 212 WRAP STYLE
PULLEY-2. 7/16 DIA. X .063 072457 6 6 6 6 9 9 9 9 9 103
+SCREW-10-32X3/8 SOCKET HEAD 600136 6 6 6 6 9 9 9 9 9 000
+KEY-1/8 SQ.X 1.50 LONG-SS 072566 6 6 6 6 9 9 9 9 9 000
RELAY-SS 25A NON-ALARM 240 VAC 074210-02 1 1 1 1 1 103 REPLACES X72729 - UPPER
CONTROL
RELAY-3P-40A 110/120 COIL 050841-12 1 1 103
RELAY-3P-50A 110/120 COIL 051890-12 1 1 2 103 208V 60HZ 3PH UPPER
CONTROL
RELAY-4P-40A 200/240 COIL 050869-27 2 2 2 2 2 3 103 UPPER CONTROL
