Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
176
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C844
-75
QTY.
C842
-78
QTY.
C842
-75
QTY.
C842
-60
QTY.
C842
-23
QTY.
C834
-75
QTY.
C832
-75
QTY.
C832
-28
QTY.
C832
-23
PART
NUMBER
RELAY-DPDT 100UA TO 7A 052111-12 1 103
+SOCKET-RELAY-FOR USE W/052111 052112 1 103
RELAY-SS 25A NON-ALARM 240 VAC 074210-02 10 10 10 10 15 15 15 15 15 103
ROD-RELEASE MAT. *M 11-12-15* 076155 2 2 2 2 103
ROD-RELEASE MAT. *842* FRONT 073469 3 3 3 3 103
ROD-RELEASE MAT. *842* REAR 073338 3 3 3 3 103
SCREW-1/4-20X3/8 SLTD ROUND 011694 8 8 8 4 8 8 8 8 4 000
SCREW-1/4-20X5/8 SERRATED HWH 017522 18 18 18 17 18 18 18 18 16 000
SCREW-10-24X1/4X3/8L SHOULDER 076684 * * * * * * * * * 000 *REMOVED FROM GRILLS
G8 & L8
SCREW-10-24X1/2 TORX TRUSS T20 002077 4 000
SCREW-10-32X1/2 SERRATED HWH 020982 18 18 18 18 10 10 10 10 10 000
SCREW-10-32X1/2 SLTD TRUSS 037734 12 12 12 12 30 10 30 30 30 000 PLATEN COVER
SCREW-10-32X3/8 SOCKET HEAD 600136 12 12 12 12 18 18 18 10 000
SCREW-10-32X3/8 SLTD TRUSS 024298 22 22 22 42 22 22 22 22 000
SCREW-3/8-16X1 SHC S SS 057815 12 12 12 12 12 000 BEARING BLOCKS
SCREW-3/8-16X1-1/2 SERR FLANGE 020129 3 3 3 3 3 3 3 3 3 000
SCREW-8-32X5/8 SOCKET HEAD CAP 020549 24 24 24 24 24 24 24 24 24 000
SCREW-SHOULDER 4-40X.3755 SOC 058381 6 6 6 6 9 9 9 9 9 103 PULLEY WIRE
SCREW-SHOULDER 3/8X4 SOCKET 053342 4 4 4 4 103
SCREW-SHOULDER 10-32X1/4X.125L 072849 6 103
SEAL-ARM 079952 4 4 4 4 6 6 6 6 6 000 ARM/BACKSPLASH
SEALANT-GORE-TEX 1/4 UNCOMP. R700033 10' 10 10 10 16' 16' 16' 16' 16' 000
SHEET-RELEASE-WRAP AROUND 073317 1 1 1 1 000 REPLACES 073124 SHEET
SHEET-RELEASE *C842*WRAP AROUND 073337 1 1 1 1 1 000 REPLACES 072899 SHEET
+CLIP-RELEASE MATERIAL-W/TAB 072673 8 8 8 8 9 9 9 9 9 000
SHEET-LOWER RELEASE *C842* 081433 1 1 C842-23 S/N M2107993
SHIELD-COUPLING FRONT 072926 2 2 2 2 3 3 3 3 3 000 PLATEN
SHIELD-COUPLING REAR 072927 4 4 4 4 6 6 6 6 6 103 REPLACES 070458 & 072468
SHIELD-GREASE 078285 4 4 4 4 6 6 6 6 6 103 USE - X78330-SER KIT A.
SHIELD-HEAT 072460 2 2 2 2 103
SHIELD-HEAT 072422 3 3 3 3 3 103 PLATEN A.-2600W *C842*
SHIELD-PLATE SHROUD 072465 6 6 6 6 9 9 9 9 9 103 PLATEN A.-2600W *C842*
SHIELD-PLATE SHROUD-OUTER 072466 6 6 6 6 9 9 9 9 9 103 PLATEN A.-2600W *C842*
SHIELD-PLATE TUBE 072467-1 6 6 6 6 9 9 9 9 6 103 REAR PLATEN ARM
