Taylor C844 Service Manual

177
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
160113
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C844
-75
QTY.
C842
-78
QTY.
C842
-75
QTY.
C842
-60
QTY.
C842
-23
QTY.
C834
-75
QTY.
C832
-75
QTY.
C832
-28
QTY.
C832
-23
PART
NUMBER
SHIELD-PLATE TUBE 072467 6 6 6 6 9 9 9 9 6 103 PLATEN A.-2600W *C842*
SHROUD A.-DOUBLE X72781 1 103
SHROUD A.-DOUBLE *M34* X74108 1 103
SHROUD A.-PLATEN WELDED X73120 2 2 2 2 103
SHROUD A.-PLATEN X72835 3 103 PLATEN A.-2600W *C842*
SHROUD A.-PLATEN *C842* X73466 3 3 3 3 103
SHROUD-DOUBLE *M 11-12* 073284 2 2 2 2 2 2 2 103
SOCKET-RELAY-FOR US W/052 052112 3 103
SPRING-EXTENSION 1.4X.12X8.8 074396 8 8 8 8 103
+PIN-SPRING UPPER 074399 4 4 4 4 103
SPRING-EXTENSION LATCH 072617 12 12 12 12 12 000 PLATEN SPRING
+PIN-SPRING UPPER 072542 6 6 6 6 6 000
SUPPORT-MOTOR DOUBLE 072406 3 3 3 3 3 103
+SCREW-10-32X5/8 SERRATED HWH 047925 18 18 18 18 18 000
+WASHER-#10 MEDIUM SPLIT LOCK 600123 18 18 18 18 18 000
SUPPORT-MOTOR SINGLE 072405 3 3 3 3 3 103
+SCREW-10-32X5/8 SERRATED HWH 047925 18 18 18 18 18 000
SUPPRESSOR A.-QA 250V .10 X74539 3 103
SWITCH-PRESSURE 240V,3HP 077879-C 1 1 1 1 103 AIR COMPRESSOR
SWITCH-PRESSURE 240V,3HP 063944-C 1 1 1 1 1 103 AIR COMPRESSOR
SWITCH-ROCKER-DPST-10AMP IP65 076989-WP 1 1 1 1 1 1 1 1 1 103 DOOR A.-LOWER *C842*
SWITCH-SCREW TERMINAL 075780 2 2 2 2 3 3 3 3 3 103 X72852 SWITCH A.-LATCH
*C832/C842*\COMPLETE
+COVER-TERMINAL 018590 2 3 2 2 3 103
+NUT-6-32 HEX MACHINE SCREW NUT 000927 4 4 4 4 6 000
+SCREW-6-32X1 SLTD ROUND 017056 4 4 4 4 6 000
TANK-ACCUMULATOR 10LB-NPT 078820 1 1 1 1 1 1 1 1 1 103 AIR COMPRESSOR
TRIM A.-LOWER CORNER *M15* LT X79196 1 1 1 1 103
TRIM A.-LOWER FRONT *M15* RGHT X79199 1 1 1 1 103
TRIM-LOWER DOOR *M15* 079206 1 1 1 1 103
TRIM-LOWER DOOR *C842* 072726 1 1 1 1 1 103
THERMOCOUPLE-K TYPE SS BRAID 079622 2 2 2 2 6 6 6 6 6 103 PLATEN A.-2600W * 208V
THERMOCOUPLE K *M 15 076222-K 103
THERMOCOUPLE A. X75695-K 6 6 6 6 9 9 9 9 9 103
TRANS.-100VA 120/208/240 PRI 079800 2 2 2 2 3 3 3 3 3 103 CONTROL A.-UPPER
