Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
178
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C844
-75
QTY.
C842
-78
QTY.
C842
-75
QTY.
C842
-60
QTY.
C842
-23
QTY.
C834
-75
QTY.
C832
-75
QTY.
C832
-28
QTY.
C832
-23
PART
NUMBER
TRANS.-CONT.-40VA 208/240V 053072 * * * * * * * * * 103 M5057035 & PRIOR W/LON
TRAY-ARM *C832* 072455 2 2 2 2 103
+CLAMP-HANDLE 079753 2 2 2 2 3 103
+SCREW-1/4-20X1-1/4 SERR.FLANGE 024351 2 2 2 2 6 000
TRAY-ARM 072407 3 3 3 3 3 103
+CLAMP-HANDLE 079753 3 3 3 3 3 103
+SCREW-1/4-20X1-1/4 SERR.FLANGE 024351 6 6 6 6 6 000
TRIM A.-LOWER CORNER LT X79196 1 1 1 1 1 1 1 1 1 103
TRIM A.-LOWER FRONT RGHT X79199 1 1 1 1 1 1 1 1 1 103
TUBE-.170ID X .250OD R403021 15' 15' 15' 15' 15' 15' 15' 15' 10' 000 AIR COMPRESSOR
VALVE-CHECK W/#69 ORIFICE 078332 2 2 2 2 3 3 3 3 3 103
VALVE-CHECK 1/4MP 020959 1 1 1 1 1 1 1 1 1 103 AIR COMPRESSOR
VALVE-PRESSURE RELIEF 70 PSI 072695-4 1 1 1 1 1 1 1 1 103
VALVE-SOLENOID 3 WAY 12 VDC 072695-1 2 2 2 2 3 3 3 3 103
VARISTOR A.-115VAC X51727-C 2 2 2 103
VARISTOR A.-230VAC W/#10 SPADE X51733-C 2 2 2 2 2 2 103
VARISTOR A.-14VAC W/#6 SP X52192 3 3 103 C84275GWR3 OR C844
SERIES 92 *FRANCE*
ROHS 400V50HZ 3N 4WIRE
VALVE A.-LATCH 951 *C842* X72931-02 1* 103 *C84275GW51 *AUSTRALIA
BRACKET-VALVE *C842* 072932 1 103
FILTER-1/4 FPT-AUTODRAIN 077017 1 000
BRACKET-FILTER *951* 077009 1 103
SCREW-8-32X3/8 UNSLTD HEX WS 041951 2 000
FITTING-1/4MPTX1/4OD TUBE 90 052560-2 2 103
TUBE-.170 ID X .250 OD 052561-10 1 000
TUBE-.170 ID X .250 OD 052561-26 3 000
CONNECTOR-MATE LOCK 6 CIR-PI 028594 1 000
PIN-.084 OD/14-20 AWG-STRIP 021624 6 000
SCREW-10-32X1/2 SLTD ROUND 007834 2 000
SCREW-10-32X1-3/4 SLTD RND 013195 2 000
NUT-10-32 SMALL PATTERN SS 059663 2 000
AVAILABLE FOR SERVICE
GAGE A.-GAP *C842/4/5* X73655
TOOL-GAPPING LRS FRANKE 081297 S/B B15012 5/14/15
