Taylor C844 Service Manual

179
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
150722
C83675GW00 & C83875GW00 ELECTRIC - 400V 50HZ 3N~ (4 WIRE) 1 PLATEN-2/3 GRILL
DESCRIPTION PART
NUMBER
QTY.
C836
-75
QTY.
C838
-75
WARR.
CLASS
REMARKS
BAR A.-RELEASE X73315 2 2 103
BAR A.-RELEASE MATERIAL X73118 2 2 103
BAR-BELLY 077904 1 1 103
+SCREW-3/8-16X1 HEX HEAD CAP 079145 2 2 000
+WASHER-3/8 USS FLAT CR3 000653 2 2 000
BEARING 3/4 ID-SELF ALIGN 078730 2 2 103
BEARING .753 X 1.000 X 2.500 074398 2 2 103
BEARING-FLANGE 3/4 X 15/16 077042 4 4 000
BLOCK-CONTACT 1 NO 076013 2 2 103 PANEL A.-LIGHT BOX/BLOCKS
BLOCK-TERMINAL 1P 073423 1 1 103
BLOCK-TERMINAL 2P .25 SPADE 051644 1 1 103 CONTROL A.-UPPER *C842*
BLOCK-TERMINAL 3P 20A, 300V 051331 2 2 103
BLOCK-TERMINAL 4P 1,2,L1,N 051647 1 1 103 CONTROL A.-UPPER *C842*
BUTTON-OPERATOR-BLACK 076012 1 1 103 PANEL A.-LIGHT BOX/BLOCKS
BUTTON-OPERATOR-RED 076011 1 1 103 PANEL A.-LIGHT BOX/BLOCKS
+GUARD-LENSE 075288 1 1 103
+LABEL-CONTROL PANEL-INTL SYMBL 075699-SYM 1 1 000
BUSHING-SNAP 11/16 ID X 7/8OD 010548 3 3 103 PANEL A.-LIGHT BOX/BLOCKS
BUSHING-SNAP 1-3/8ID X 1-3/4OD 027712 1 1 103
BUSHING-SNAP 15/16 ID X 1-3/32 023396 3 3 103
BUSHING-SNAP 1-5/8ID X 2 OD 043637 1 1 103
CABLE-ADJUST-PLATEN 072458 3 3 103
CASTER-5" 7-5/8 STEM 078377 2 2 103
CASTER-GRILL 5" SWIVEL W/LOCK 073240 2 2 103
CLEVIS-ROD 1/2-20 THD 079777 1 1 103
CLIP-RELEASE MATERIAL-W/TAB 072673 8 8 000
COMPRESSOR-AIR-230V SERV 032129SER2 1 1 212 400V 50HZ 3N~ (4 WIRE)
+ADAPTOR-HI TEMP 1/4X1/4 OD 058769-2 1 1 103
+FITTING-HI TEMP 1/4X1/4 OD 90 058771-2 1 1 103
+MANIFOLD A. 073129-R 1 1 103
+PLUG-1/4MP BRASS 027747 1 1 103
+PLUG-HOLE 7/8 DIA. BLACK 010077 1 1 000
+SWITCH-PRESSURE 240V,3HP 077879-C 1 1 103
+TANK-ACCUMULATOR 10LB-NPT 078820 1 1 103
