Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
180
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C838
-75
QTY.
C836
-75
PART
NUMBER
+TEE-HI TEMP 1/4X1/4 OD 058770-2 1 1 103
+TUBE-TEFLON .188IDX.250OD R403022 3' 3' 000
+VALVE-CHECK 1/4MP 020959 1 1 103
CONTROL-GATEWAY-LON X72848-SER * * 212 USED S/N M5057035 & PRIOR WITH LON
CONTROL-DISPLAY X72491-SER 1 1 212 DOOR A.-LOWER *C842* - DISPLAY
+GASKET-CONTROL 072914 1 1 000
+NUT-8-32 KEPS ZINC/TRI 081547 2 2 000
+WASHER-#8 EXTERNAL TOOTH LOCK 000964 2 2 000
CONTROL-HI-LIMIT 550F NO RESET 074165 7 7 103 PLATEN A.-2450W
CONTROL-MOTOR INTERFACE X72436-SER 1 1 212 CONTROL A.-LOWER
+SCREW-6-32X5/8 UNSLTD HWH 041363 3 3 000
COVER A.-PLATEN X73116 1 1 103
COVER A.-PLATEN X73117 1 1 103
BAR A.-RELEASE MATERIAL X73118 2 2 103
NUT-10-32 WHIZ FLANGE LOCKNU 020983 6 6 000
CYLINDER-AIR 6IN STROKE C/C 079160 1 1 103
DIAGRAM-WIRING 083305-75 1 1 000
DOOR A.-CONTROL X83093 1 1 103
E-RING-3/4 STEEL 077046 4 4 000
FASTENER-SNAP IN 1/4X15/16 078329 8 8 000
FILTER-CORCOM 2VR1 032567 1 1 103 CONTROL A.-UPPER *C842*
FILTER A.-*M15* WHT/BLK X78996-40 1 1 103
FITTING-HI TEMP 1/4X1/4 OD 9 058771-2 3 3 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-5 1 1 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-6 1 1 103
FITTING-DIFFUSER 1/4 MPT 072695-8 1 1 103
FORM-QUALITY REPORT BY FAX 065712 1 1 000
FUSE-4 AMP BK/MDL-4-R 079837-040 1 1 000
+HOLDER-FUSE-15 A, 250 V 076299 1 1 103
FUSE-6 AMP. 076301 1 1 000
GUARD-LENSE 075288 1 1 103
HANDLE-PLATEN 072472 1 1 103
HARNESS A.-COMP. VALVE *C820* X73703-R
HARNESS A.-PCB 073473 1 1 103
HARNESS A.-MOTOR 073472 1 1 103
