Taylor C844 Service Manual

181
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C838
-75
QTY.
C836
-75
PART
NUMBER
HARNESS A.-COMP/TB X79503 1 1 103
HARNESS A.-RELAY/PCB X74222 1 1 103
HEATER-CAST 945W 230VAC 074266-26 6 103
HEATER-CAST 1035W 077910-26 6 103
HINGE A.-M.P.DOOR-RIGHT X78348 1 1 103
HINGE A.-M.P. DOOR-LEFT X78349 1 1 103
HOLDER-DRIP TRAY 074206 1 103
HOLDER-DRIP TRAY 077943 1 103
HOOK-SHEET LEFT 074184 1 1 103
HOOK-SHEET RIGHT 074185 1 1 103
KIT A.-3FT RESTRAIN CABLE 074948 1 1 103
KIT A.-ACCESSORY X73142-SER 1 1 103
CLIP-RELEASE MATERIAL-W/TAB 072673 8 8 000
SCREW-10-32X3/8 SLTD TRUSS 024298 9 9 000
SCREW-3/8-16X1 HEX HEAD CAP 001082 2 2 000
WASHER-3/8 USS FLAT CR3 000653 2 2 000
KIT A.-GREASE SHIELD* X78330-SER 1 1 000
+FASTENER-SNAP IN 1/4X15/16 078329 8 8 000
+SHIELD-GREASE 078285 2 2 000
KIT A.-MOTOR X73998-SER 3 3 103
MOTOR-BLDC 073998 3 3 103
TIE-CABLE .19WX7-3/8L HI-TEM 051033 9 9 000
+SCREW-10-32X1-5/8 SOC. HD CAP 079117 12 12 000
+WASHER-#10 EXTERNAL TOOTH LOCK 002681 12 12 000
+WASHER-#10 FLAT 18-8 SS 037841 12 12 000
LABEL-CONTROL PANEL-INTL SYM 075699-SYM 1 1 000
LABEL-ELEC-CAUTION 075484 1 1 000
LABEL-HOOD ID 079156 1 1 000
LABEL-OPER 079519 1 1 000
LABEL-WARN GRILL-MCD-SVC-F/G 072658-FG 3 3 000
LABEL-WARRANTY-MCD 056691 1 1 000
LABEL-WIRING CONTR 079538-12 1 1 000
MAN-OPER C836/C838 073530-M 1 1 000
MANIFOLD A.-AIR COMPRESSOR 073129-R 1 1 103
CONNECTOR-MATE LOCK 4 CIR-PIN 500534 1 1 103

Taylor C844 Specifications

General

Brand	Taylor
Model	C844
Category	Grill
Language	English
