Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
182
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C838
-75
QTY.
C836
-75
PART
NUMBER
FITTING-DIFFUSER 1/4 MPT 072695-8 1 1 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-5 1 1 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-6 1 1 103
GAUGE-130 PSI 1/8 MPT BACK M 072695-3 1 1 103
PIN-.084 OD/14-20 AWG-STRIP 021624 2 2 103
REGULATOR-PRESSURE 0-120 PSI 072695-2 1 1 103
SCREW-M3X0.5 072695-10 2 2 000
VALVE-PRESSURE RELIEF 80 PSI 072695-12 1 1 103
VALVE-SOLENOID 3 WAY 12 VDC 072695-1 1 1 103
O-RING-1-3/16OD X .103W 052733-120 4 4 000 REAR PLATEN ARM
O-RING-1-1/16OD X .103W 052733-118 2 2 000
PANEL A.-BACK SERVICE X83555 1 1 103
PANEL A.-SWITCH X83535 1 1 103
PANEL-SIDE-R 083504 1 103
PANEL-SIDE UPPER-R 083503 1 103
PANEL-SIDE-L 083506 1 103
PANEL-SIDE UPPER-L 083505 1 103
PANEL-SIDE *C832* 073345-R 1 103
PANEL-SIDE UPPER-RT *C832 073353 1 103
PANEL-SIDE *C832* 073345-L 1 103
PANEL-SIDE UPPER-LT *C832 073352 1 103
PCB A.-INTERF MTR X73633-SER 1 1 212 MOTOR A.-MOUNT
MOUNT-PCB +072898 1 1 103
SCREW-6-32X5/8 SLTD ROUND +019309 6 6 000
PLATEN A.-3100W SERV*-WRAP X73333-75S 1 1 212
PLUG-HOLE 1-3/4 DIA 027132 1 1 000
PULLEY-2. 7/16 DIA. X .063 072457 3 3 103
+SCREW-10-32X3/8 SOCKET HEAD 600136 3 3 000
+KEY-1/8 SQ.X 1.50 LONG-SS 072566 3 3 000
RELAY-4P-40A 200/240 COIL 050869-27 1 1 103 UPPER CONTROL
RELAY-SS 25A NON-ALARM 240 VAC 074210-02 5 5 103
ROD-RELEASE MAT. 076155 1 1 103
SCREW-SHOULDER 4-40X.3755 SOC 058381 3 3 103 PULLEY WIRE
SCREW-SHOULDER 3/8X3-1/4 052010 5 5 103
SCREW-1/4-20X3/8 SLTD ROUND 011694 4 4 000
