Taylor C844 Service Manual

183
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C838
-75
QTY.
C836
-75
PART
NUMBER
SCREW-10-24X1/4X3/8L SHOULDER 076684 2 2 000
SCREW-10-24X1/2 TORX TRUSS T20 002077 6 6 000
SCREW-10-32X1/2 SERRATED HWH 020982 10 10 000
SCREW-10-32X3/8 SLTD TRUSS 024298 24 24 000
SCREW-3/8-16X1 HEX HEAD CAP 079145 24 24 000
SCREW-8X1/2 SLTD HEX WASHER 075763 12 12 000
SEAL-ARM 079952 2 2 000 ARM/BACKSPLASH
SEALANT-GORE-TEX 1/4 UNCOMP. R700033 5' 5' 000
SEALANT-JOINT .065 THK X .50 R700032 5' 5' 000 GORE-TEX
SEALANT-JOINT 1/2 IN TEADIT R70003 3' 3' 000
SHEET-RELEASE *C832/C835*-WRAP AROUND 073317 1 1 000
+CLIP-RELEASE MATERIAL-W/TAB 072673 8 8 000
SHIELD-COUPLING FRONT 072926 1 1 000 PLATEN
SHIELD-COUPLING REAR 072927 2 2 103 REPLACES 070458 & 072468
SHIELD-GREASE 078285 2 2 103
SHIELD-HEAT 072460 1 1 103
SHIELD-PLATE SHROUD 072465 3 3 103 PLATEN A.-2600W *C842*
SHIELD-PLATE SHROUD-OUTER 072466 3 3 103 PLATEN A.-2600W *C842*
SHIELD-PLATE TUBE 072467-1 3 3 103 REAR PLATEN ARM
SHIELD-PLATE TUBE 072467 3 3 103 PLATEN A.-2600W *C842*
SHROUD A.-LOWER X74260 1 103
SHROUD A.-LOWER X74042 1 103
SPRING-EXTENSION 1.4X.12X8.8 074396 4 4 103
+PIN-SPRING UPPER 074399 2 2 103
SWITCH-PRESSURE 240V,3HP 077879-C 1 1 103 AIR COMPRESSOR
SWITCH-ROCKER-DPST-10AMP IP65 076989-WP 1 1 103 DOOR A.-LOWER *C842*
SWITCH-SCREW TERMINAL 075780 1 1 103 X72852 SWITCH A.-LATCH *C832/C842*\COMPLETE
+COVER-TERMINAL 018590 1 1 103
+NUT-6-32 HEX MACHINE SCREW NUT 000927 2 2 000
+SCREW-6-32X1 SLTD ROUND 017056 2 2 000
TANK-ACCUMULATOR 10LB-NPT 078820 1 1 103 AIR COMPRESSOR
THERMOCOUPLE-K TYPE SS BRAID 079622 1 1 103 PLATEN A.-2600W *C842* 208V
THERMOCOUPLE A. X75695-K 3 3 103
TRANS.-100VA 120/208/240 PRI 079800 1 1 103 CONTROL A.-UPPER *C842*
TRANS.-CONT.-40VA 208/240V 053072 * * 103 USED S/N M5057035 & PRIOR WITH LON
