Taylor C844 Service Manual

185
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
150722
C83523N000 - 208V 60HZ 3PH, C83528N000 - 240V 60HZ 3PH, C83560NW00 - 220/380V 60HZ 3PH-4, C83575NW00 - 400 50HZ 3N~ (4 WIRE),
C84523N000 - 208V 60HZ 3PH, C84560NW00 - 220/380V 60HZ 3PH-4 WIRE, C84575NWRO - 400V 50HZ 3N~, C84578NW00 - 220V 50/60HZ 3PH
DESCRIPTION PART
NUMBER
QTY.
C835
-23
QTY.
C835
-28
QTY.
C835
-60
QTY.
C835
-75
QTY.
C845
-23
QTY.
C845
-60
QTY.
C845
-75
QTY.
C845
-78
WARR.
CLASS
REMARKS
208V
60HZ
3PH
240V
60HZ
3PH
220/
380V
60HZ
3PH
400V
50HZ
3N~
208V
60HZ
3PH
220/
380V
60HZ
3PH
400V
50HZ
3N~
220V
50/60
HZ
3PH
ADAPTOR 076745 2 2 2 2 3 3 3 3 103
ARM A.-TUBE *C832* LEFT X72475-L 1 1 1 1 103
+SEAL-ARM 079952 2 2 2 2 000
ARM A.-TUBE *C832* RIGHT X72475-R 1 1 1 1 103
+SEAL-ARM 079952 2 2 2 2 000
ARM A.-TUBE *C845* X73031 3 3 3 3 103
+SEAL-ARM 079952 6 6 6 6 000
BACKSPLASH A.-*C832/C835* X73126 1 1 1 1 103
BACKSPLASH A. X73637 1 1 1 1 103
BAR A.-RELEASE *C832/C835* X73315 4 4 4 4 103
BAR A.-RELEASE MATERIAL*832/35 X73118 4 4 4 4 103
BAR A.-RELEASE MATERIAL X72843 6 6 6 6 103
+NUT-10-32 WHIZ FLANGE LOCKNUT 020983 18 18 18 18 000
+SCREW-SHOULDER 10-32X1/4X.125L 072849 12 12 12 12 000
BAR-BELLY 075663-SP 1 1 1 1 103
+SCREW-3/8-16X1 HEX HEAD CAP 079145 2 2 2 2 000
+WASHER-3/8 USS FLAT CR3 000653 2 2 2 2 000
BEARING 3/4 ID-SELF ALIGN 078730 4 4 4 4 6 6 6 6 103
BEARING .753 X 1.000 X 2.500 074398 4 4 4 4 103
BEARING .753 X 1.000 X 2.000 072541 6 6 6 6 000
BEARING-FLANGE 3/4 X 15/16 077042 8 8 8 8 12 12 12 12 000
BLOCK-CONTACT 1 NO *11/12/15 076013 4 4 4 4 6 6 6 6 103 PANEL A.-LIGHT BOX/BLOCKS
BLOCK-TERMINAL 1P 073423 1 1 1 1 4 3 3 4 103
BLOCK-TERMINAL 2P .25 SPD-24X 073033 2 2 2 2 103
BLOCK-TERMINAL 2P .25 SPADE 051644 2 2 2 2 103 CONTROL A.-UPPER
BLOCK-TERMINAL 3P 20A, 300V 051331 2 2 1 1 4 4 4 103
BLOCK-TERMINAL 4P 1,2,L1,N 051647 1 1 1 1 1 1 1 1 103 CONTROL A.-UPPER
BLOCK-TERMINAL 5P 20A, 30 024329 2 2
PLATE-TERMINAL BLOCK *C845* 081089-1 1 1 1 1
BLOWER A.-WUTG SHIELD *C835* X80906 2 2 103 REPLACES X73326 3/23/11
