Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
186
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
FAN-BLOWER 60CFM 120/230 VAC 079326-12 2 2 3 3 3 3 103
SHIELD-AIRFLOW 073325 2 2 103
BULLNOSE A. ***** 1 1 1 1 SEE DRIPEDGE X79036
BURNER-33% OPEN-CENTER IND 079327 2 2 2 2 212
BURNER-I.R.*C845* 073334 3 3 3 3 103
+GASKET-BURNER BRACKET *M15* 079087 2 2 2 2 3 3 3 3 000
BUTTON-OPERATOR-BLACK 076012 2 2 2 2 3 3 3 3 103 PANEL A.-LIGHT BOX/BLOCKS
BUTTON-OPERATOR-RED 076011 2 2 2 2 3 3 3 3 103 PANEL A.-LIGHT BOX/BLOCKS
+GUARD-LENSE 075288 2 2 3 3 3 103
+LABEL-CONTROL PANEL-INTL SYMBL 075699-SYM 1 1 2 2 000
BUSHING-ANTI-SHORT 1/2 020735 4 4 4 4 6 6 6 6 000
BUSHING-ANTI-SHORT 3/8 019117 2 2 2 2 000
BUSHING-SNAP 11/16 ID X 7/8OD 010548 9 9 9 6 6 6 6 6 103 PANEL A.-LIGHT BOX/BLOCKS
BUSHING-SNAP 1-3/8ID X 1-3/4OD 027712 4 4 5 4 4 6 6 4 103
BUSHING-SNAP 1-5/8ID X 2 043637 1 1 103
BUSHING-SNAP .391 ID X.500 OD 073910 3 3 3 3 3 103
CABLE-ADJUST-PLATEN 072458 6 6 6 6 9 9 9 9 103
CABLE-LON GATEWAY *C842* 072916-42 * * * * 103 USED M5057035 & PRIOR W/LON
CABLE-LON GATEWAY *C842* 072916-43 * * * * 103 USED M5057035 & PRIOR W/LON
CABLE-LON GATEWAY *C842* 072916-52 * * * * 103 USED M5057035 & PRIOR W/LON
CABLE-LON GATEWAY *C842* 072916-53 * * * * 103 USED M5057035 & PRIOR W/LON
CABLE-LON GATEWAY *C842* 072916-63 * * * * 103 USED M5057035 & PRIOR W/LON
CARD-CHECKOUT INTELLIGAP GAS 073291 1 1 1 1 1 1 1 000
CASTER-5" 7-5/8 STEM 078377 2 2 2 2 2 2 2 2 103
CASTER-GRILL 5" SWIVEL W/LOCK 073240 2 2 2 2 2 2 2 2 103
CATCH-DOOR 073613 1 1 1 1 103
CLEVIS-ROD 1/2-20 THD 079777 2 2 2 2 3 3 3 3 103
CLIP-PLASTIC 017609 2 2 2 2 103
CLIP-RELEASE MATERIAL-W/TAB 072673 8 8 8 8 9 9 9 9 000
COMPRESSOR-AIR-115V 60HZ 075506SER1 1 1 1 212 208V 60HZ 3PH
COMPRESSOR-AIR-230V SERV 032129SER2 1 1 1 1 1 212 400V 50HZ 3N~ (4 WIRE)
+ADAPTOR-HI TEMP 1/4X1/4 OD 058769-2 1 1 1 1 1 1 1 1 103
+CROSS-1/4 FPT * 1.562 SQ 077339-M 1 1 1 1 1 103
+ ELBOW-1/4PT-STREET-BRASS 035573 1 1 1 1 1 103
+FITTING-HI TEMP 1/4X1/4 OD 90 058771-2 1 1 1 1 1 1 1 1 103
