Taylor C844 Service Manual

187
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
+MANIFOLD A.-*C832* 073129 1 1 1 1 103
+MANIFOLD A.-*C842* 072695 1 1 1 1 103
+PLUG-1/4MP BRASS 027747 1 1 1 1 1 1 1 1 103
+PLUG-HOLE 7/8 DIA. BLACK 010077 1 1 1 1 1 1 1 1 000
+PLUG-1/4 NPT-PARKER:VS219P-4 065156-6 1 1 1 1 1 103
+SWITCH-PRESSURE-240V, 3HP 063944-C 1 1 1 1 103 M3107231 REPLACES 063944-C -
U/D 233
+SWITCH-PRESSURE 240V,3HP 077879-C 1 1 1 1 1 1 1 1 103
+TANK-ACCUMULATOR 10LB-NPT 078820 1 1 1 1 1 1 1 1 103
+TEE-1/4FPT X 1/4MPT X 1/4FPT 021277 1 1 1 103
+TEE-HI TEMP 1/4X1/4 OD 058770-2 1 1 1 1 1 1 1 1 103
+TUBE-TEFLON .188IDX.250OD R403022 10' 10' 10' 10' 10' 10' 10' 10' 000
+VALVE-CHECK 1/4MP 020959 1 1 1 1 1 1 1 1 103
+VARISTOR A.-115VAC X51727-C 2 2 103
+VARISTOR A.-230VAC W/#10 X51733-C 2 2 2 2 2 2 103
CONNECTOR-MATE LOCK-3 CIR-PIN 044823 4 4 5 5 5 5 5 5 103 PANEL A.-LIGHT BOX/BLOCKS
CONNECTOR-MATE LOCK-9 CIR-PIN 078020 2 2 2 2 3 3 3 3 103
CONTROL-DISPLAY X72491-SER 2 2 2 2 3 3 3 3 212 DOOR A.-LOWER - DISPLAY
+GASKET-CONTROL *C842* 072914 2 2 2 2 3 3 3 3 000
+NUT-8-32 HEX M/S NUT SMALL 000969 4 4 4 4 6 6 6 6 000
+WASHER-#8 EXTERNAL TOOTH LOCK 000964 4 4 4 4 6 6 6 6 000
CONTROL-GATEWAY-LON X72848-SER * * * * * * * * 212 USED M5057035 & PRIOR W/LON
+BRACKET A.-FILTER-LON X80726 * * 103 USED M5057035 & PRIOR W/LON
+BRACKET A.-FILTER-LON X73705 * * 103 USED M5057035 & PRIOR W/LON
+BRACKET-LON CONTROL*C832/C834* 073232 * * 103 USED M5057035 & PRIOR W/LON
+BRACKET-LON CONTROL *C834* 073482-1 * * 103 USED M5057035 & PRIOR W/LON
+BRACKET-LON CONTROL *C845* 073482 * * * * 103 USED M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-42 * * * 103 USED M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-52 * * * 103 USED M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-43 * * * * * * 103 USED M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-53 * * * * 103 USED M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-63 * * * * * * 103 USED M5057035 & PRIOR W/LON
+FILTER-CORCOM 2VR1 032567 * * * * * * * * 103 USED M5057035 & PRIOR W/LON
+FILTER-EMI-LINE-250V50/60HZL 073245 * * * * 000 USED M5057035 & PRIOR W/LON
+FILTER A.-*C835* LON X79256-L * * 103 USED M5057035 & PRIOR W/LON
