Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
188
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
+SCREW-10X3/8 SLOTTED HEX WSH 015582 * * * * * * * * 000 USED M5057035 & PRIOR W/LON
+SCREW-6-32X5/8 UNSLTD HWH 041363 * * * * * * * * 000 USED M5057035 & PRIOR W/LON
+SCREW-8X1/4 SLTD HEX WASHER 009894 * * * * * * * * 000 USED M5057035 & PRIOR W/LON
+SCREW-10-32X3/8 UNSL HWH SER 039381 * * * * 000 USED M5057035 & PRIOR W/LON
+TRANS.-CONT.-40VA 208/240V 053072 * * * * * * * * 103 USED M5057035 & PRIOR W/LON
CONTROL-HI-LIMIT 450F RESET 070279 2 2 3 3 3 103
CONTROL-HI-LIMIT 550F NO RESET 074165 4 4 3 103 PLATEN A.-2450W
CONTROL-IGNITOR UTC *M35* X70301-02S 2 2 3 3 103
CONTROL-IGNITION 24VAC ROHS 081041-03 2 2 3 3 103 ROHS - REPLACES 080890-03
CONTROL-LIMIT W/SCREWS 078721 6 6 3 3 103 PLATEN A.-2600W
CONTROL-MOTOR INTERFACE X72436-SER 2 2 2 2 212 CONTROL A.-LOWER
CONTROL-MOTOR *C845* X69875-SER 3 3 3 3 212
CORD-1.5MM-3 HAR7 16GA 60 051656-158 1 103
CORD-2.6MM-5 HAR7 26A 60D 054832-158 1 103
COVER A.-PLATEN *C832/C835* X73116 2 2 2 2 103
COVER A.-PLATEN *C832* X73117 2 2 2 2 103
BAR A.-RELEASE MATERIAL*832/ X73118 4 4 4 4 103
NUT-10-32 WHIZ FLANGE LOCKNU 020983 12 12 12 12 000
COVER A.-PLATEN *C842* X73365 3 3 3 3 103
COVER-FRONT *C811* 073963 2 2 2 2 1 1 1 103
CYLINDER-AIR 6IN STROKE C/C 079160 2 2 2 2 3 3 3 3 103
DIAGRAM-WIRING *C835* LVI 073181-23 1 000
DIAGRAM-WIRING *C835* LVI 073181-28 1 000
DIAGRAM-WIRING *C835* HVI 073181-60 1 000
DIAGRAM-WIRING *C835* HVI 073181-75 1 000
DIAGRAM-WIRING *C845* 073090-23 1 1 000
DIAGRAM-WIRING *C845* 081641-60 1 000
DIAGRAM-WIRING *C845* 073700-40 1 000
DIAGRAM-WIRING *C845* 073090-78 1 000
DIODE A.-50 PIV 1A X73238 2 2 000
DIODE A.-50 PIV 1A X73673 3 3 3 000
DOOR A.-CONTROL *C832* X72485 1 1 103
DOOR A.-CONTROL *C835* HV X73172 1 1 103
DOOR A.-CONTROL *C842* X73397 1 1 1 1 103
DRIPEDGE A.-SERVICE X79036 1 1 1 1 103
