Taylor C844 Service Manual

189
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
E-RING-3/4 STEEL 077046 8 8 8 8 12 12 12 12 000
E-RING 1/4 BLACK PHOS 032190 4 4 4 4 6 6 6 6 000
KIT A.-GAS PILOT ELECTRODE X81683-SER 2 2 2 2 103 C835 DOMESTIC -23 & -28 / S/N
M3107363 & UP
GASKET-ELECTRODE REPLACEMENT 073529 2 2 2 2 000
SLEEVE-COMPRESSION FTG-3/16 081370 2 2 2 2 000
NUT-COMPRESSION 3/16 081371 2 2 2 2 000
ELECTRODE WITH SHIELD X81660-SER * * 103 S/N M3107362 & PRIOR -
REPLACES 076373
GASKET-ELECTRODE REPLACEMENT 073529 * * 000
ELECTRODE N/A USE X81660-SER 076373 * * * * 103 USE X81660-SER UNITS PRIOR TO
M3107362
KIT A.-ELECTRODE *C835* X81660-SER 2 2 2 2 103
KIT A.-GAS PILOT ELECTRODE X81758-SER 3 3 3 3 103 C845 S/N M4011597 & UP
REPLACED 073810 & 080879
GASKET-ELECTRODE REPLACEMENT 073529 3 3 3 3 000
SLEEVE-COMPRESSION FTG-3/16 081370 3 3 3 3 000
NUT-COMPRESSION 3/16 081371 3 3 3 3 103
KIT A.-GAS PILOT ELECTRODE X81758-SER 3 3 3 3 103 S/N M4011597 & UP
ELECTRODE-GAS PILOT 080879 * * * * 103 N/A USE X81758-SER S/N
M4011597 & UP
ELECTRODE 073810 3 3
ELECTRODE 073409
ELECTRODE 073810 * * * * 103 USE S/N M2125254 & PRIOR
FAN-BLOWER 60CFM 120/230 VAC 079326-12 2 2 2 2 3 3 3 3 103
+SHIELD-AIRFLOW 073325 2 2 2 2 103
FASTENER-SNAP IN 1/4X15/16 078329 16 16 16 16 24 24 24 000
FILTER-CORCOM 2VR1 032567 2 2 2 2 * * * * 103 USED M5057035 & PRIOR W/LON
FILTER-EMI-LINE-250V50/60HZL 073245 1 1 1 1 000
FILTER-CORCOM 6EH1 040140-001 3 3 3 3 103
FILTER A.-*M15* WHT/BLK X78996-40 1 1 1 1 103
FILTER A.-*M22E* WHT/BLK X79256 1 1 103
FILTER A.-*C835* LON X79256-L 1 1 103
FITTING-1/4MPTX1/4OD TUBE 90DG 052560-2 4 4 4 4 6 6 6 103
FITTING-UNION 1/2" BLACK PIPE 078645 1 1 1 1 103
