Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
190
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
FORM-QUALITY REPORT BY FAX 065712 1 1 1 1 1 1 1 000
FUSE-7 AMP MDQ-7 079837-070 1 1 000
+HOLDER-FUSE-15 A, 250 V 076299 1 1 103
FUSE-4 AMP BK/MDL-4-R 079837-040 1 1 000
+HOLDER-FUSE-15 A, 250 V 076299 1 1 1 103
FUSE-10 AMP BK/MDA-10-R 079837-10 1 1 1 1 000 S/N M2021925 & UP REPLACED
079837-070
FUSE-6 AMP. 076301 1 1 1 1 1 1 1 000
GASKET-BRAIDED-HI TEMP R70113 9' 9' 9' 9' 15' 15' 15' 15' 000
GASKET-FRONT SHROUD *C835* 081771 1 1 1 1 000 C835 S/N M3107363 U/D 233
GASKET-FRONT SHROUD 072983 1 1 1 1 000
GASKET-FRONT VIEW PORT M14-1 076380 2 2 2 2 000
GASKET-FRONT VIEW PORT *C845 072985 3 3 3 3 000
GASKET-GORE-TEX .250 DIA 000 SEE - R700032 SEALANT-JOINT
GASKET-GORE-TEX .250 DIA - NLA 000 SEE - R700033 SEALANT
GUIDE-CHECKOUT INTELLIGAP GAS 073291-MCD 1 1 1 1 000
GUIDE-CHECKOUT INTELLIGAP GAS 073291-MCD 1 1 1 1 000
GUIDE-PATTY PLACEMNT 072912 1 1 1 1 103
GUARD-LENSE 075288 2 2 3 103
+LABEL-CONTROL PANEL-INTL SYMBL 075699-SYM 1 1 1 000
HANDLE-PLATEN *C832/C842* 072472 2 2 2 2 3 3 3 3 103
HARNESS-BLOWER 073420 3 3 103
HARNESS-BLOWER 073608 3 103
HARNESS A.-BLOWER *C845* 081596 1 1 103 S/N M3010000 & UP
HARNESS A.-CNTL BOX X74157 1 1 1 1 1 103 S/N K7120000 & UP
HARNESS A.-COMP. VALVE X72743 1 103 S/N K7120000 & UP - REPLACES
X72854
HARNESS A.-COMP. VALVE *C832* X73145 1 1 1 1 103
HARNESS A.-COMP/TB X79503 1 1 1 1 103
HARNESS A.-GAS VALVE X79573-24 1 1 103
HARNESS A.-GAS VALVE X79573-36 1 1 3 3 103
HARNESS A.-GAS VALVE *M15E* X79511 1 2 103
HARNESS A.-GAS VALVE X79511-40 2 2 3 103
HARNESS A.-GAS VALVE *M35* X79357 1 1 103
HARNESS A.-GAS VALVE *M35* X79357-22 1 1 103
