Taylor C844 Service Manual

191
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
HARNESS A.-IGN CNTRL *C845* 081595 3 3 103 S/N M3010000 & UP
HARNESS A.-MOTOR FEM *C84 073643 2 2 2 2 3 3 3 3 103
HARNESS A.-MOTOR *C842* 073472 2 103
HARNESS A.-PCB *C842* 073473 2 2 2 2 3 3 3 3 103
HARNESS-COMPRESSOR 073422 1 1 1 103
HARNESS-COMPRESSOR *C845/ 073422 1 103
HARNESS-IGNITOR-GROUND 073438 1 1 1 1 103
HARNESS-LON/CONTACTOR *C845 081600 1 1 103
HARNESS-MC TO SSR *C845* 081587 1 103 S/N M3010000 & UP
HARNESS-MC BOARD SUPPLY-2 073460 1 103
HARNESS-PCB/GR SWITCH 072529 2 2 2 2 3 3 3 3 103 CONTROL A.-LOWER *C842*/J3
HARNESS-PCB/LOGIC 072527 2 2 2 2 3 3 3 3 103 CONTROL A.-LOWER *C842*
HARNESS-POWER SUPPLY-NEG 073436 1 1 103
HARNESS-PRESSURE SWITCH 073444 1 1 103
HARNESS-RELAY/PCB *C835* 073168 2 2 103
HARNESS-RELAY/PCB *C835* HV 073237 2 2 103
HARNESS-SSR-LEFT*C845* 073095 1 1 103
HARNESS-SSR-MIDDLE*C845* 073096 1 1 103
HARNESS-SSR-RIGHT*C845* 073097 1 1 103
HARNESS-SSR-LEFT 073801 1 103
HARNESS-SSR-MIDDLE 073802 1 103
HARNESS-SSR-RIGHT 073803 1 103
HARNESS-SWITCH*C845* 073424 1 1 1 103
HEATER-1100W-208V 076654 2 103
+RELAY-SS 25A NON-ALARM 240 V 074210-02 6 103 041951 SCREW
HEATER-1100W-240V 076767 2 103
+RELAY-SS 25A NON-ALARM 240 V 074210-02 6 103 041951 SCREW
HEATER-1100WATT 220VOLT 076801 2 103
+RELAY-SS 25A NON-ALARM 240 V 074210-02 6 103 041951 SCREW
HEATER-CAST-1100W *M15E/35* 079583-26 2 103
+RELAY-SS 25A NON-ALARM 240 V 074210-02 6 103 041951 SCREW
HINGE A.-M.P.DOOR-RIGHT X78348 1 1 1 1 103
HINGE A.-M.P. DOOR-LEFT X78349 1 1 1 1 103
HOOK-SHEET M32/35 LEFT 074184 2 2 2 2 103
HOOK-SHEET M32/35 RIGHT 074185 2 2 2 2 103
