Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
192
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
HOSE-BEV.-.250IDX.438OD-100' R30317 5' 5' 5' 5' 7' 7' 7' 7' 103
+CLAMP-HOSE 7/16-WIRE DICHROM 051742 3 3 3 3 000
HOSE ASSEMBLY-FLEXIBLE GAS 076390 1 1 1 1 103
HOSE ASSEMBLY-FLEXIBLE GAS 073677 1 1 1 1 103
INSULATOR-TEFLON-2 HOLE 079810 4 4 4 4 6 6 6 6 000
KIT A.-3FT RESTRAIN CABLE 074948 1 1 1 1 1 1 1 1 103
KIT A.-ACCESSORY *M832/835* X73142-SER 1 1 1 1 103
CLIP-RELEASE MATERIAL-W/TAB 072673 8 8 8 8 000
SCREW-10-32X3/8 SLTD TRUSS 024298 9 9 9 9 000
SCREW-3/8-16X1 HEX HEAD CAP 001082 2 2 2 2 000
WASHER-3/8 USS FLAT CR3 000653 2 2 2 2 000
KIT A.-ACCESSORY X72886-SER 1 1 1 1 000
CLIP-RELEASE MATERIAL-W/TAB 072673 6 6 6 6 000
ROD-RELEASE MAT. *842* REAR 073338 3 3 3 3 000
SCREW-10-32X3/8 SLTD TRUSS 024298 9 9 9 9 000
SCREW-3/8-16X1 HEX HEAD CAP 001082 2 2 2 2 000
WASHER-3/8 USS FLAT CR3 000653 2 2 2 2 000
KIT A.-GAS VALVE 1/2" NPT 072569 4 4 6 6 103
KIT A.-GAS VALVE 24 VAC X81823-SER 3 3 103 REPLACES 078909-03
KIT A.-GREASE SHIELD* X78330-SER 2 2 2 2 3 3 3 3 000
LABEL-CONTROL PANEL-INTL 075699-SYM 1 1 2 2 2 000
LABEL-ELEC-CAUTION 075484 1 1 1 1 1 1 1 1 000
LABEL-EQUIPOTENTIAL CONNECTOR 076406 1 1 1 1 1 1 1 000 CONTROL BOX
LABEL-INST-LIGHT*15E* 079567 1 1 000
LABEL-MOTOR *C842* 073620 1 1 1 1 000
LABEL-NOTICE-CASTERS 076389 1 1 000
LABEL-OPERATION*C842/C844* 072865 1 1 1 1 1 1 1 1 000
LABEL-WARN-GAS GRILL 078075 1 1 1 1 1 000
LABEL-WARN GRILL MCD AUTH SVC 072658 3 3 3 3 3 3 3 000
LABEL-WARRANTY-MCD 056691 1 1 1 1 1 1 1 000
LENS-MICA *C845* 072986 3 3 3 3 000
LINE A.-GAS-LEFT *C835* X81714 1 1 103 C835 DOMESTIC S/N M3107363 &
UP-U/D 233
LINE A.-GAS-RIGHT *C835* X81710 1 1 103 C835 DOMESTIC S/N M3107363 &
UP-U/D 233
