McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
LINE-GAS *M25* RIGHT 079119 1 1 103
LINE-GAS *M25* LEFT 079120 1 1 103
LINE A.-GAS-LEFT *C811* X81004 1 1 103 S/N M2125255 & UP
LINE A.-GAS-CENTER *C811* X81005 1 1 103 S/N M2125255 & UP
LINE A.-GAS-RIGHT *C811* X81006 1 1 103 S/N M2125255 & UP
LINE A.-GAS-LEFT *C811/C845* X81068 1 1 103 S/N M2125255 & UP
LINE A.-GAS-CENTER *C811/C84 X81069 1 1 103 S/N M2125255 & UP
LINE A.-GAS-RIGHT *C811/C845 X81070 1 1 103 S/N M2125255 & UP
LUG-GROUNDING 4-14GA WIRE 017667 3 3 3 3 3 3 3 000
MAN-OPER C835 073292-M 1 1 1 1 000
MAN-OPER C845 073452-M 1 1 1 000
MAN-OPER C845 SPANISH 073452SM 1 1 1 000
MANIFOLD A.-*C832* - AIR COMPRESSOR 073129 1 1 1 1 103 AIR COMPRESSOR
BLOCK MANIFOLD .030 ORFICE 073129-7 1 1 1 1 103
CONNECTOR-MATE LOCK 4 CIR-PIN 500534 1 1 1 1 103
FITTING-DIFFUSER 1/4 MPT 072695-8 1 1 1 1 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-5 1 1 1 1 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-6 1 1 1 1 103
GAUGE-130 PSI 1/8 MPT BACK M 072695-3 1 1 1 1 103
PIN-.084 OD/14-20 AWG-STRIP 021624 4 4 4 4 103
PLUG-1/8 MP-NICKEL PLATED 020988 1 1 1 1 103
REGULATOR-PRESSURE 0-120 PSI 072695-2 1 1 1 1 103
SCREW-M3X0.5 072695-10 4 4 4 4 000
VALVE-PRESSURE RELIEF 70 PSI 072695-4 1 1 1 1 103
VALVE-SOLENOID 3 WAY 12 VDC 072695-1 1 1 1 1 103
MANIFOLD A.-C842/C844 072695 1 1 1 103 AIR COMPRESSOR
CONNECTOR-MATE LOCK 6 CIR-PI 028594 1 1 1 103
FITTING-DIFFUSER 1/4 MPT 072695-8 1 1 1 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-5 3 3 3 103
FITTING-SWIVEL ELBOW 1/4 OD 072695-6 1 1 1 103
GAUGE-130 PSI 1/8 MPT BACK M 072695-3 1 1 1 103
PIN-.084 OD/14-20 AWG-STRIP 021624 6 6 6 103
PLUG-1/8 MP-NICKEL PLATED 020988 1 1 1 103
REGULATOR-PRESSURE 0-120 PSI 072695-2 1 1 1 103
SCREW-M3X0.5 072695-10 6 6 6 000
