+ Available Separately, NNN = Not a Service Item
194
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
VALVE-PRESSURE RELIEF 70 PSI 072695-4 1 1 1 103
VALVE-SOLENOID 3 WAY 12 VDC 072695-1 3 3 3 103
MANIFOLD A.-GAS *M15E* 3.5WC X79373-02 1 1 103
MANIFOLD A.-GAS *M15E* X78891-40 1 1 103
MANIFOLD A.-*C845* GAS X73109-02 1 1 1 103
KIT A.-MOTOR C842 X73998-SER 6 6 6 6 9 9 9 103 REPLACES 072454
NUT-8-32 KEPS ZINC/TRI 081547 12 12 12 12 18 18 18 000
ORIFICE A.-IGNITOR - RED 073826-003 2 2 103 S/N M3107363 & UP - U/D 233
ORIFICE A.-IGNITOR - YELLOW 073826-005 2 2 3 3 3 3 103 C835 S/N M3107363 C845 S/N
M2125255 & UP
+COVER-ORIFICE *C845* 081089-2 1 1 1 1 000
ORIFICE-HEX PLUG GAS-#34 076554-34 2 2 2 2 103
ORIFICE-HEX PLUG GAS-#52 076554-52 2 2 103
ORIFICE-HEX PLUG-#47 076554-47 2 2 103
ORIFICE-HEX PLUG GAS-#51 076554-51 3 3 3 3 103 S/N M3012438 & UP- REPLACES
076554-53
+COVER-ORIFICE *C845* 081089-2 1 1 1 1 000
ORIFICE-HEX PLUG GAS-#40 076554-40 3 3 3 3 103
O-RING-1-3/16OD X .103W 052733-120 8 8 8 8 12 12 12 000 REAR PLATEN ARM
O-RING-1-1/16OD X .103W 052733-118 4 4 4 4 6 6 6 000
PANEL A.-BACK PNL X72958-SER 1 1 103 S/N K8102227 & UP
PANEL A.-BACK SERVICE *C835* X73152 1 1 1 1 103
PANEL A.-CONTROL UPPER *C845 X73697 1 103
PANEL A.-LIGHT *M25* X78845 1 1 1 1 103
PANEL A.-SIDE UPPER LT X72962 1 1 1 1 103 S/N K8102227 & UP
PANEL A.-SIDE UPPER RT X72965 1 1 1 1 103 S/N K8102227 & UP
PANEL-BACK TW0 SPEED FAN 072959 1 1 103 8/01/08 REPLACES 074085
PANEL-SIDE LEFT 072967 1 1 1 1 103 S/N K8102227 & UP
PANEL-SIDE RIGHT 072968 1 1 1 1 103 S/N K8102227 & UP
PANEL A.-BACK PNL *C845* X73680-SER 1 1 1 103
PANEL A.-BACK SERVICE X73681 1 103
PANEL A.-CONTROL UPPER *C845 X73697 1 103
PANEL-SIDE UPPER-LT *C832* 073352 1 1 1 1 103
PANEL-SIDE UPPER-RT *C832* 073353 1 1 1 1 103
PANEL-SIDE *C832* 073345-L 1 1 1 1 103
