McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
PANEL-SIDE *C832* 073345-R 1 1 1 1 103
PCB A.-INTERF MTR *C832/C842* X73633-SER 2 2 2 2 3 3 3 212
PLATE A.-TERMINAL BLOCK *C845* X81090 1 1 103
PLATE A.-TERMINAL BLOCK *C8 X81090-2 1 103 C845-75 REPLACED X81090-2
M3043702
PLATE A.-TERMINAL BLOCK *C845* X81090-3 103 C845-75 REPLACES X81090-4
PLATE A.-TERMINAL BLOCK *C845* X81090 1 103
PLATE-TERMINAL BLOCK *C845* 081089-1 1 1 1 1 103
DIODE A.-50 PIV 1A X73673 3 3 000
SCREW-8X1/4 SLTD HEX WASHER 009894 5 1 5 000
BLOCK-TERMINAL 3P 20A, 300V 051331 2 2 103
ORIFICE A.-IGNITOR 073826-003 3 3 3 3 103
COVER-ORIFICE *C845* 081089-2 1 1 1 1 103
PLATEN A.-3100W SERV *C832/C835 X73333-23 2 212
PLATEN A.-3100W SERV*C832/C835-WRAP X73333-75 2 2 2 212
PLATEN A.-2600W SER*C842/C845* X73598-23 3 212
PLATEN A.-2450W SERV C842/C844 X73599-75 3 212 REPLACED X73598-75
PLATEN A.-2600W 230V *C845 X73491-78 3 212
PLUG A.-POWER *C842* X72734 1 103
PULLEY-2. 7/16 DIA. X .063 072457 6 6 6 6 9 9 9 103
+SCREW-10-32X3/8 SOCKET HEAD 600136 6 6 6 6 9 9 9 000
+KEY-1/8 SQ.X 1.50 LONG-SS 072566 6 6 6 6 9 9 9 000
RELAY A.-3 HEATER *M35* X74213 2 2 2 2 103
RELAY A.-HEATER *C845* X81645 1 1 103
RELAY A.-HEATSINK *C845* X81644 1 1 103
RELAY-3P-40A 110/120 COIL 050841-12 1 1 103
RELAY-3P-40A 208/240 COIL 050841-27 1 103
RELAY-3P-50A 110/120 COIL 051890-12 1 103 208V 60HZ 3PH UPPER CONTROL
RELAY-4P-40A 200/240 COIL 050869-27 1 1 1 1 103 UPPER CONTROL
RELAY-DPDT 100UA TO 7A 1/8HP 052111-03 2 2 3 3 3 103
+SOCKET-RELAY-FOR USE W/052111 052112 2 2 3 3 3 103
RELAY-SS 25A NON-ALARM 240 VAC 074210-02 6 6 6 6 6 6 6 103
+PLATE-HEATSINK *C845* GAS 072980 1 1 1 103
+SCREW-10-32X1/2 SERRATED HWH 020982 12 12 12 000
ROD-RELEASE MAT. *M 11-12-15* 076155 2 2 2 2 103
