Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
196
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
ROD-RELEASE MAT. *842* FRONT 073469 3 3 3 103
ROD-RELEASE MAT. *842* REAR 073338 3 3 3 103
SCREW-1/4-20X3/8 SLTD ROUND 011694 24 24 24 24 24 24 24 000
SCREW-1/4-20X5/8 SERRATED HWH 017522 15 15 15 15 18 18 18 000
SCREW-10-24X1/4X3/8L SHOULDER 076684 2 2 2 2 000
SCREW-10-24X1/2 TORX TRUSS T20 002077 8 8 8 8 16 16 16 000
SCREW-10-32X1/2 SERRATED HWH 020982 29 29 29 29 22 22 22 000
SCREW-10-32X1/2 SLTD TRUSS 037734 12 12 12 12 30 30 30 000 PLATEN COVER
SCREW-10-32X3/8 SOCKET HEAD 600136 26 26 26 000
SCREW-10-32X3/8 SLTD TRUSS 024298 89 89 89 89 42 42 42 000
SCREW-3/8-16X1 SHC S SS 057815 12 12 12 000 BEARING BLOCKS
SCREW-3/8-16X1-1/2 SERR FLANGE 020129 3 3 3 3 3 3 3 000
SCREW-8-32X5/8 SOCKET HEAD CAP 020549 24 24 24 24 24 24 24 000
SCREW-SHOULDER 4-40X.3755 SOC 058381 6 6 6 6 9 9 9 103 PULLEY WIRE
SCREW-SHOULDER 3/8X3-1/4 052010 4 4 4 4 103
SCREW-SHOULDER 10-32X1/2 SS 057584 2 2 2 103
SEAL-ARM 079952 4 4 4 4 6 6 6 000 ARM/BACKSPLASH
SEALANT-GORE-TEX 1/4 UNCOMP. R700033 10' 10' 10' 10' 16' 16' 16' 000
SHEET-RELEASE *C832* BOX OF 6-STD 073124 1 1 000
SHEET-RELEASE -WRAP AROUND 073317 1 1 000
SHEET-RELEASE *C842*WRAP AROUND 073337 1 1 1 1 000
SHEET-LOWER RELEASE *C832 081432 1 1 1 1 000 C835 S/N M2111829 & UP -23 & -28
ONLY
SHEET-LOWER RELEASE *C842 081433 1 000
+CLIP-RELEASE MATERIAL-W/TAB 072673 8 8 8 8 9 9 9 000
SHIELD-AIRFLOW 073325 2 2 000
SHIELD-COUPLING FRONT 072926 2 2 2 2 3 3 3 000 PLATEN
SHIELD-COUPLING REAR 072927 4 4 4 4 6 6 6 6 103 REPLACES 070458 & 072468
SHIELD-GREASE 078285 4 4 4 4 6 6 6 6 103 ORDER X78330-SER KIT A.
+FASTENER-SNAP IN 1/4X15/1 078329 16 16 16 16 34 34 34 34 000
SHIELD-HEAT 072460 2 2 2 2 103
SHIELD-HEAT 072422 3 3 3 103 PLATEN A.-2600W *C842*
SHIELD-PLATE SHROUD 072465 6 6 6 6 3 9 3 103 PLATEN A.-2600W *C842*
SHIELD-PLATE SHROUD-OUTER 072466 6 6 6 6 9 9 9 103 PLATEN A.-2600W *C842*
SHIELD-PLATE TUBE INNER 072467-1 6 6 6 6 6 6 6 6 103 REAR PLATEN ARM
