Taylor C844 Service Manual

197
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
SHIELD-PLATE TUBE 072467 6 6 6 6 6 6 6 6 103 PLATEN A.-2600W *C842*
SHROUD A.-COMBINATION *C835* X81769 1 1 1 1 103 C835 S/N M3107363 U/D 233
+GASKET-FRONT SHROUD *C835* 081771 1 1 1 1 000 C835 S/N M3107363 U/D 233
SHROUD A.-COMBINATION X73965 1 1 1 1 103 M1105009 & UP - REPLACES
X72998
+GASKET-FRONT SHROUD 072983 1 1 1 1 000
SHROUD A.-PLATEN WELDED X73120 2 2 2 2 103
SHROUD A.-PLATEN *C842* X73466 3 3 3 103
SPRING-EXTENSION 1.4X.12X8.8 074396 8 8 8 8 103
+PIN-SPRING UPPER 074399 4 4 4 4 103
SPRING-EXTENSION LATCH 072617 12 12 12 12 000 PLATEN SPRING
+PIN-SPRING UPPER 072542 6 6 6 6 000
SUPPORT-MOTOR DOUBLE 072406 3 3 3 3 103
+SCREW-10-32X5/8 SERRATED HWH 047925 18 18 18 18 000
+WASHER-#10 MEDIUM SPLIT LOCK 600123 18 18 18 18 000
SUPPORT-MOTOR SINGLE 072405 3 3 3 3 103
+SCREW-10-32X5/8 SERRATED HWH 047925 18 18 18 18 000
SWITCH-PRESSURE 074314 2 2 2 2 3 3 3 3 103
SWITCH-PRESSURE 240V,3HP 077879-C 1 1 1 1 1 1 1 103 AIR COMPRESSOR
SWITCH-ROCKER-DPST-10AMP IP65 076989-WP 1 1 1 1 1 1 1 1 103 DOOR A.-LOWER *C842*
SWITCH-SCREW TERMINAL 075780 2 2 2 2 3 3 3 3 103 X72852 SWITCH A.-LATCH
TANK-ACCUMULATOR 10LB-NPT 078820 1 1 1 1 1 1 1 103 AIR COMPRESSOR
THERMOCOUPLE-K TYPE SS BRAID 079622 2 2 2 2 6 6 6 6 103 PLATEN A.-2600W *C842* 208V
THERMOCOUPLE K *M 15 076222-K 2 2 2 2 6 6 6 6 103
THERMOCOUPLE A. X75695-K 2 2 2 2 103
TRANS.-100VA 120/208/240 PRI 079800 2 2 2 2 3 3 3 103 CONTROL A.-UPPER *C842*
TRANS.-CONT.-40VA 208/240V 053072 * * * * * * * * 103 USED M5057035 & PRIOR W/LON
TRANS.-CONT.-80VA 230V/24V 059993 2 2 3 3 103
TRANS.-100VA 120/208/240 079800-24 3 3 103
TRAY-ARM *C832* 072455 2 2 2 2 103
+CLAMP-HANDLE 079753 2 2 2 2 103
+SCREW-1/4-20X1-1/4 SERR.FLANGE 024351 4 4 4 4 000
TRAY-ARM 072407 3 3 3 3 103
+CLAMP-HANDLE 079753 3 3 3 3 103
+SCREW-1/4-20X1-1/4 SERR.FLANGE 024351 6 6 6 6 000
