Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
198
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C845
-78
QTY.
C845
-75
QTY.
C845
-60
QTY.
C845
-23
QTY.
C835
-75
QTY.
C835
-60
QTY.
C835
-28
QTY.
C835
-23
PART
NUMBER
TRIM A.-LOWER CORNER *M15* LT X79196 1 1 1 1 103
TRIM A.-LOWER FRONT *M15* RGHT X79199 1 1 1 1 103
TRIM-LOWER DOOR *M15* 079206 1 1 1 1 103
TUBE-.170ID X .250OD R403021 7' 7 7 7 10' 10' 10' 10' 000 AIR COMPRESSOR
TUBE-TEFLON .188IDX.250OD R403022 10' 10' 10' 10' 000
VALVE-CHECK W/#69 ORIFICE 078332 2 2 2 2 3 3 3 3 103
VALVE-CHECK 1/4MP 020959 1 1 1 1 1 1 1 1 103 AIR COMPRESSOR
VALVE-GAS REDUNDANT 3-1/2 WC 079329-02 3 3 103
VALVE-GAS REDUNDANT 24VAC 078909-03 3 3 103 N/A USE X81823-SER KIT A.
KIT A.-GAS VALVE 24 VAC X81823-SER 3 3 103 REPLACES 078909-03
VALVE-PRESSURE RELIEF 70 PSI 072695-4 1 1 1 1 1 1 1 1 103
VALVE-SOLENOID 3 WAY 12 VDC 072695-1 2 2 2 2 3 3 3 3 103
VARISTOR A.-115VAC X51727-C 2 2 103
VARISTOR A.-230VAC W/#10 SPADE X51733-C 2 2 2 2 2 2 103
VARISTOR-280VAC RMS 17 MM DIA 030036 2 2 103
WINDOW-GAS GRILL *M 14-15 076375 2 2 2 2 103
WINDOW-FRONT VIEW PORT *C 073013 3 3 3 3 103
+LENS-MICA *C845* 072986 3 3 3 3 000
WIRE A.-IGNITOR *C845* X73147-12 2 2 2 2 103 C835 DOMESTIC -23 & -28 / S/N
M3107363 & UP
WIRE A.-IGNITOR *M15E* X78902-12 * * * * 103 S/N M3107262 & PRIOR
WIRE A.-IGNITOR *C845* X73147-12 3 3 3 3 103
CANADA - C83423NACE & C84523NWGX - LABELS
CARD-INSTALL-GAS GRILL-FRENCH 044218-F 1 000
CARD-INSTALL-C845 FRENCH- 073618FC 1 000
LABEL-ELEC-CAUTION-F/G 075484-FG 1 000
LABEL-HOOD ID-FRENCH/GERMAN 079156-FG 1 000
LABEL-HOOD ID-CANADA-ENG/ 079156-CAN 1 000
LABEL-INST-LIGHT*15E*FRENCH 079567-F 1 1 000
LABEL-NOTICE-CASTERS-F/G 076389-FG 1 1 000
LABEL-OPERATION*C842/C844*FREN 072865-F 1 1 000
LABEL-WARN-GAS GRILL-F/G 078075-FG 1 1 000
LABEL-WARN-GRILL-MCD-SVC-CAN 072658-CAN 3 3 000
MAN-OPER C845 FRENCH CANA 073452FCM 1 000
