13
C856 Exploded View (See Figure 6.)
ITEM PART NO. DESCRIPTION QTY. FUNCTION WARR.
CLASS
1 X84971 CAN A.-GREASE-L 2 Container for grease. 103
2 X84248 SHROUD A.-UPPER*L 1 Metal bracket that the grease can
slides into, securing it next to the
lower grill plate.
103
3 070695 SCREW-10-32X1/2 PHIL 4 Fastens bumper onto panel. 000
4 084549 BUMPER 1 Protects grill from damage. 000
5 X73600-SER KIT A.-GREASE SHIELD 4 Fastens grease shields to rear shroud. 000
6 084215 PANEL-REAR 1 Provides access to internal
components for service and cleaning.
103
7 024298 SCREW-10-32X3/8 SLTD
TRUSS
54 Secures the panel to the frame. 000
8 084250 PANEL-SIDE-RIGHT 1 Provides access to internal
components for service and cleaning.
103
9 078377 CASTER-5” 7-5/8 STEM 2 Allows grill mobility. 103
10 X85465 SHIELD A.-REAR GRS 2 Prevents grease migration. 103
11 X84246 SHROUD A.-UPPER*R 1 Metal bracket that the grease can
slides into, securing it next to the
lower grill plate.
103
12 073240 CASTER-5” 7-5/8
SWIVEL W/LOCK
2 Prevents grill movement. 103
13 X84526 CAN A.-GREASE-R 2 Container for grease. 103
14 076989-WP SWITCH-ROCKER-
DPST 10A
1 Activates power to the grill and the
exhaust fans.
103
15 083786 TOUCHSCREEN-UI 2 Controls all functions of the grill. - - -
16 X84504 DOOR A.-WELDED 2 Houses the controls and the fan
interlock switch.
103
17 068583 COVER A.-USB
WATERPROOF
2 Protects USB port from water
damage.
103
18 075288 GUARD-LENSE 2 Protects the Standby button and and
accidentally starting a cook cycle For
international use only.
000
19 076012 BUTTON-OPERATOR-
BLACK
2 Activates the cook cycle, keeps the
upper platen in the closed position,
and displays the message
“STANDBY” on the control. When
pressed twice with one second
intervals between presses, the upper
platen will automatically lower into the
Standby position.
000
20 076011 BUTTON-OPERATOR-
RED
2 Cancels the Standby mode, raises the
upper platen, and deactivates the
Cook cycle.
000
21 084251 PANEL-SIDE-LEFT 1 Provides access to internal
components for service and cleaning.
103
22 084550 BUMPER 1 Protects grill from damage. 000
