ENGLISH - 22
REMOVING AND CLEANING BEATER
Pull the beater upwards to pull it out of the tub.
Emerge the previously disassembled component into
the tub with the sanitizer and brush the surfaces with
care. Pay special attention to the inner duct of the
beater shaft.
REMOVING AND CLEANING THE TAP
Rotate the tap block anticlockwise and of 90° until
releasing it.
Pull the block tap until removing it from the machine.
Remove the drain pipe pos 8 and remove the OR
gasket pos. 7, using the provided tool 7
Loosen the hand wheel pos. 1 and remove the piston
pos 5.
Emerge the previously disassembled components
into the tub with the sanitizer and brush the surfaces
with care. Pay special attention to the inner duct of
the tap, to the holes and seats of the OR.
All the disassembled parts must remain soaking in the Ecolab P3 Topax-san sanitizer
(4% dilution) for at least 15’ before they are rinsed with plenty of cold drinking water.
SANITIZING FIXED PARTS
While the removable parts soak in the sanitizer
inside the tub, proceed sanitizing the fixed parts of
the machine:
SANITIZING THE TUB
Immerse a disposable paper cloth in the sanitising
liquid.
Pass the cloth over all the surfaces of the tub and
fixed transmission shaft.
Pass the cloth over the outer edge of the tub until
reaching the surfaces of the cover and front panel.
