Taylor Frigomat CH02 Series User Manual

APPENDICI - 6
CH02 s05 Tav.1
P. COD. DESCRIZIONE DESCRIPTION DESCRIPTION BESCHREIBUNG DESCRIPTION
1
A06.185
Gruppo isolamento Insulation unit Groupe isolant Isolationsgruppe Grupo aislamiento
2
E15.40826
Scheda pulsantiera
Pushbutton panel
card
Carte du tableau de
commande
Tastenkarte
Tarjeta caja
pulsadores
-
E13.38654
Cavo scheda
pulsantiera
Wiring pushbutton
panel card
Cable carte du
tableau de
d
Tastenkarte-Kabel
Cablo tarjeta caja
pulsadores
3
E15.40831
Scheda comando Control card Carte de commande Bedienungskarte Tarjeta de mando
4
M02.38287
Etichetta anteriore Front label Etiquette antérieure Frontkleber Etiqueta anterior
5
P14.37043
Piedino Foot Pied Fuss Pie
6
F03.325
Protezione fondo Bottom guard Protection du fond Bodenschutz Protección Fondo
7
A02.38240
Carenatura anteriore Front panel Panneau Frontal Vordere Blechtafel Panel anterior
8
P06.077
Piedino Foot Pied Fuss Pie
9
F01.160
Telaio Frame Châssis Gestell Armazón
10
C03.189
Pannello posteriore Back panel Panneau postérieur Hinteres Blech Panel posterior
11
L19.37042
Perno cerniera Hinge Pin Goujon pour fermoir Scharnierstift Perno para bisagra
12
B15.037
Cerniera fissa Fixed hinge Fermoir fixe Festes Scharnier Bisagra fija
13
B15.038
Cerniera mobile Moving hinge Fermoir mobile
Bewegliches
Scharnier
Bisagra móvil
14
B09.215
Vite cerniera Hinge screw Vis pour fermoir Scharnierschraube Tornillo para bisagra
15
P16.37041
Coperchio Cover Couvercle deckel Tapa
