11
C801/C801R/F802/P802/C803/C803R/C804 Operator Parts Identification
C803
Figure 5
ITEM DESCRIPTION PART NO.
1 HANDLE-LIFT-PLATEN 072711
2 HANDLE-ADJUST-PLATEN 070647
3 PLATEN A.-ADJUSTABLE SERV X71825-23
4 PLATEN A.-*C801* 4 OZ SERV X71824-23
5 PLATEN A.-*C801* 2 OZ SERV X71823-23
ITEM DESCRIPTION PART NO.
6 SHIELD-BACKSPLASH 070765
7 DIVIDER A.-COOK 070851
8 DIVIDER A.-2 LANE STAGE 070847
9 DIVIDER A.-3 LANE STAGE 070848
