18
C801/C801R/F802/P802/C803/C803R/C804Important: To the Operator
F802 Front Unit
Figure 12
ITEM DESCRIPTION PART NO.
1 NODE A.-COMPLETE F802
STAGE/COOK
X71550-SER
2 CONTROL-C801 MODE I/O 071242-SER
ITEM DESCRIPTION PART NO.
3 LIGHT-RED 230V 070880-27
4 CONTROL-RESET SWITCH
10A/250
070717
