Taylor QS Series - Page 34


46 6HULHV
3DUWV
46 6HUYLFH 3DUWV ([SORGHG 9LHZ
,7(0 '(6&5,37,21 3$57 12
1 PLATE A.-LOWER X79254
1a CHUTE A.-GREASE X78419
2 LEG-4”-3/8-16 STUD 036397
3 STANDOFF-FRONT 079289
4 COVER A.-BOTTOM X79527
5 PANEL-REAR 079280
6 STANDOFF-REAR 079288
7 SCREW-10-32X3/8 TRUSS HD 024298
8 SHIELD-GREASE REAR 079434
9 BRACKET A.-SHIELD RIGHT X79431
,7(0 '(6&5,37,21 3$57 12
10 SHIELD-GREASE FRONT 079433
11 BRACKET A.-SHIELD LEFT X79429
12 WIPER-REAR 079440
13 COVER A.-REAR X79444
14 BRACKET-MTG SIDE RIGHT 079436
15 WIPER-SIDE RIGHT 079438
16 GUARD A.-FRONT X79426-SP
17 WIPER-FRONT 079439
18 BRACKET-MTG SIDE LEFT 079435
19 WIPER-SIDE LEFT 079437
