8
Operator Parts Identification
Models QS12 & QS24
071102
Section 4 Operator Parts Identification
QS12
O
N
O
F
F
1
2
3
4
Figure 12
ITEM DESCRIPTION PART NO.
1 STANDOFF-REAR 079288
2 STANDOFF-FRONT 079289
3 TRAY A. - GREASE X79940-SER
ITEM DESCRIPTION PART NO.
4 COVER-TOP 079969
* CLEANER-SIZZLE 079896
*NOT SHOWN
