Additional informations
TBS CLOUD
All TBS Crossfire transmitters and the Fusion video receivers include a built-in WiFi module which allows
you to connect all your gear through the TBS Cloud. This allows to use features like VTX follow*, dynamic
VTX power* and other upcoming features.
*TBS Fusion video receiver required
Menu
● WiFi Client
○ AP Mode: enables/ disables the WiFI module
○ Default SSID: enables/ disables the SSID broadcast of Crossfire TX hotspot
○ SSID: SSID/ name of the selected external hotspot
○ Password: password for external selected hotspot
○ Connect: manually connect to the network. Only necessary when a new network is chosen
in
SSID
option
○ Scan: scans for WiFI networks. Found networks can be chosen under
SSID
, manual
reconnect by
Connect
is required
○ Forget WiFi: erases all saved networks and their passwords
○ Upgrade: starts the self update for the WiFI firmware. Disabled at the moment
● UDP
○ MAVLink: enables/ disables the sending of MAVlink data over the wifi
○ Port: change the UDP port where the telemetry will be send
● WebUI
○ AP Lock: enables/ disables password authentication for Crossfire TX internal WiFi hotspot
○ Password: set up a password for Crossfire TX internal WiFi hotspot
○ Login: enables/ disables password authentication for Crossfire TX internal Web Ui
○ Password: set up a password for Crossfire TX internal Web Ui
● About
○ WiFi: name of the WiFi hotspot/ Network your Crossfire is connected to
○ IP: IP address the Crossfire module was assigned by WiFi network
○ Server: connection status
○ Firmware: version number of the WiFI firmware
○ Hardware: hardware revision of the WiFI module
○ Bootloader: version number of the WiFi Bootloader firmware
○ Serial Number: serial number of the WiFi module
Initiate the WiFi module
