TC Electronic Flashback Mini Delay User Manual

Inputs, outputs and controls
Flashback Mini Delay – Manual (2014-05-26) 17
Audio in and out
Audio input
The audio input on the right side of this pedal is
a standard ¼” jack (mono/TS).
– Connect your guitar to the audio input on the
right side of your pedal using a regular ¼”
mono cable.
Audio output
The audio output on the left side of this pedal is
a standard ¼” jack (mono/TS).
– Connect the audio output of your pedal to the
next device in the signal chain using a regular
¼” mono cable.
USB port
Use the standard Mini-B USB port on your TC
Electronic effect pedal to connect your pedal to
a computer. This will allow you to load TonePrints
into the pedal or create your own TonePrint us-
ing TC’s TonePrint Editor. For more information,
see “TonePrint”.
If there should be firmware updates for this ped-
al, they can also be installed using the USB port
– see “Updating the firmware”.
Effect controls
Please note that the knob assignments on your
TC Electronic effect pedal are the default as-
signments. Using the TonePrint Editor, you can
rewire all knobs so they control one or several
parameters of your choice. For more information,
see the TonePrint Editor manual.
DELAY knob – Delay time control
Use the DELAY knob to control the delay time.
Almost all delay types have a delay range of
20ms to 7000ms (that’s seven seconds). Slap-
back (“SLP”) has a range from 20ms to 300ms.
FEEDBACK knob – Feedback control
Use the FEEDBACK knob to set the desired
numbers of delay repeats. Turning the FEED-
BACK knob to the right will give you more delay
repeats.
FX LEVEL knob – Effect level control
Use the FX LEVEL knob to control the level of the
delay repeats.
The direct, unprocessed signal is always passed
at the original level (unity gain). Only the level of
delay repeats is changed when turning the FX
LEVEL knob.
