TC Electronic Flashback Mini Delay User Manual

Technical specifications
Flashback Mini Delay – Manual (2014-05-26) 26
Please note that due to continuous development, the following specifications are subject to change without further notice.
Bypass mode True Bypass
Signal circuitry Analog dry-through
Dimensions (width x depth x height) 48 x 48 x 93 mm – 1.9 x 1.9 x 3.7”
Input connector Standard ¼” jack – mono/TS
Output connector Standard ¼” jack – mono/TS
Power input Standard 9V DC, centre negative >100mA (power supply not included)
Battery option -
Input impedance 1MΩ
Output impedance 100Ω
USB port Mini USB connector for uploading and editing custom TonePrints and for software updates

TC Electronic Flashback Mini Delay Specifications

General

Brand	TC Electronic
Model	Flashback Mini Delay
Category	Music Pedal
Language	English
