(5) Atak - Reguluje szybkość włączania się efektu po
przekroczeniu progu.
(6) Poziom - Regulacja poziomu wyjściowego, gdy efekt
jest włączony.
(JP) コントロール類およびコネクター類
(1) Input/Output (入力/出力) ジャック – ¼インチ
ケーブルを使って、ギターを入力 (INPUT) ジャッ
ク に 接 続 し 、出 力 (OUTPUT) ジャックとお 使 い の
アンプリファーを接続します。
(2) 9 V DC – 9 V パワーサプライ (別売) を接続し
ます。
(3) Footswitch (フットスイッチ ) – エフェクトの オ
ン / オ フ を お こ な い ま す 。ペ ダ ル の 有 効 時 は LED
が点灯します。ペダルの無効時はトゥルーバイ
パ スとなります。
(4) Sustain (サステイン) – コンプレッションの量を
調 節します。
(5) Attack (アタック) – スレッショルドを 超えてか
らエフェクトが 有 効 になるまで の 速さを調 節
します。
(6) Level (レベル) – エフェクト有 効 時 の 出力レ ベ
ルを調節します。
(CN) 控制和接口
(1) Input/Output 接口 – 连接吉他的 ¼" 线到 INPUT
接口, 将插入 OUTPUT 接口的线连接到功放。
(2) 9 V DC – 连接 9 V 电源 （不随货供应）。
(3) Footswitch – 打开和关闭效果。 当踏板开启时,
LED 灯亮。 当其关闭时, 踏板工作在真正的旁通。
(4) Sustain – 调节压缩量。
(5) Attack – 调节超过阈值后效果开启的速度。
(6) Level – 当效果开启时, 调节输出电平。.
Battery Replacement
Storage
Specication
Connectors
Input
¼" TS, unbalanced
Impedance >350 k
Output
¼" TS, unbalanced
Impedance 1 k
Power input
Standard 9 V DC,
center negative, >100 mA
Battery option
Internal 9 V battery
connector
Current consumption
<10 mA
Physical
Dimensions (H x W x D)
58 x 74 x 132 mm
(2.3 x 2.9 x 5.2")
Weight
0.5 kg (1.1 lbs)
Batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, re or the like.
WARNING
• • As with all small batteries, the batteries used with this
product should be kept away from small children who still
put things in their mouths. If they are swallowed, promptly
call your local poison control center.
• • Always purchase the correct size and grade of battery most
suitable for intended use.
• • Replace all batteries of a set at the same time.
• • Clean the battery contacts and also those of the device prior
to battery installation.
• • Ensure the batteries are installed correctly with the regard
to polarity (+ and -).
• • Always remove battery if consumed or if product is to be left
unused for a long time.
• • Replacement of a battery with an incorrect type that
can defeat a safeguard! Replace only with the same or
equivalent type!
• • Risk of re or explosion if the battery is replaced by an
incorrect type.
• • disposal of a battery into re or a hot oven, or mechanically
crushing or cutting of a battery, that can result in an explosion;
• • Leaving a battery in an extremely high temperature
surrounding environment that can result in an explosion or
the leakage of ammable liquid or gas; and
• • A battery subjected to extremely low air pressure that may
result in an explosion or the leakage of ammable liquid
or gas.
• • Attention should be drawn to the environmental aspects of
battery disposal.
LEGAL DISCLAIMER
Music Tribe accepts no liability for any loss which may be suered
by any person who relies either wholly or in part upon any
description, photograph, or statement contained herein. Technical
specications, appearances and other information are subject
to change without notice. All trademarks are the property of
their respective owners. Midas, Klark Teknik, Lab Gruppen, Lake,
Tannoy, Turbosound, TC Electronic, TC Helicon, Behringer, Bugera,
Aston Microphones and Coolaudio are trademarks or registered
trademarks of Music Tribe Global Brands Ltd. © Music Tribe Global
Brands Ltd. 2021 All rights reserved.
LIMITED WARRANTY
For the applicable warranty terms and conditions and additional
information regarding Music Tribe’s Limited Warranty, please see
complete details online at Community.musictribe.com/pages/
support#warranty.
NEGACIÓN LEGAL
Music Tribe no admite ningún tipo de responsabilidad por
cualquier daño o pérdida que pudiera sufrir cualquier persona
por conar total o parcialmente en la descripciones, fotografías o
armaciones contenidas en este documento. Las especicaciones
técnicas, imágenes y otras informaciones contenidas en este
documento están sujetas a modicaciones sin previo aviso.
Todas las marcas comerciales que aparecen aquí son propiedad
de sus respectivos dueños. Midas, Klark Teknik, Lab Gruppen, Lake,
Tannoy, Turbosound, TC Electronic, TC Helicon, Behringer, Bugera,
Aston Microphones y Coolaudio son marcas comerciales o marcas
registradas de Music Tribe Global Brands Ltd. © Music Tribe Global
Brands Ltd. 2021 Reservados todos losderechos.
GARANTÍA LIMITADA
Si quiere conocer los detalles y condiciones aplicables de la
garantía así como información adicional sobre la Garantía
limitada de Music Tribe, consulte online toda la información en la
web Community.musictribe.com/pages/support#warranty.
DÉNI LÉGAL
Music Tribe ne peut être tenu pour responsable pour toute
perte pouvant être subie par toute personne se ant en partie
ou en totalité à toute description, photographie ou armation
contenue dans ce document. Les caractéristiques, l’apparence
et d’autres informations peuvent faire l’objet de modications
sans notication. Toutes les marques appartiennent à leurs
propriétaires respectifs. Midas, Klark Teknik, Lab Gruppen, Lake,
Tannoy, Turbosound, TC Electronic, TC Helicon, Behringer, Bugera,
Aston Microphones et Coolaudio sont des marques ou marques
déposées de Music Tribe Global Brands Ltd. © Music Tribe Global
Brands Ltd. 2021 Tous droits réservés.
GARANTIE LIMITÉE
Pour connaître les termes et conditions de garantie applicables,
ainsi que les informations supplémentaires et détaillées sur
la Garantie Limitée de Music Tribe, consultez le site Internet
Community.musictribe.com/pages/support#warranty.
2
FORCEFIELD COMPRESSOR
