TECHNICAL SPECIFICATIONS
46
Digital Inputs and Outputs
Connectors:
Formats:
Sample Rates:
Analog Inputs
Connectors, balanced:
Impedance - Balanced/Unbalanced
Line Input Level @ 0 dBFS:
Line Sensitivity @ 12 dB headroom:
Drive Input Level @ 0 dBFS:
Drive Sensitivity @ 12 dB headroom:
THD:
Crosstalk:
A to D Conversion:
Analog Outputs
D to A Conversion:
D to A Delay:
Connectors, balanced:
Output Impedance:
Max. Output Level
(Balanced/Unbalanced):
Output Range:
Dynamic Range:
THD:
Frequency Response:
EMC
Complies with:
Safety
Certified to:
Environment
Operating Temperature:
Storage Temperature:
Humidity:
Control Interface
MIDI:
Pedal:
Supplementary
Display:
Dimensions:
Weight:
Mains Voltage:
Power Consumption:
Warranty Parts and labor:
RCA Phono (S/PDIF)
S/PDIF (24 bit), EIAJ CP-340, IEC 958
44.1 kHz, 48 kHz
¼"phone jack
Line: 21/13 kOhm
24 dBu to 0 dBu
12 dBu to -12 dBu
18 dBu to -6 dBu
6 dBu to -18 dBu
< -100 dB (0,001 %) @ 1 kHz
<-85 dB, 20 Hz to 20 kHz
24 bit, 128 x oversampling bitstream
24 bit, 128 x oversampling bitstream
0.63/0.68 ms @ S.R.= 48/44.1 kHz
¼"phone jack
40 Ohm
20 dBu/14 dBu, R-load = 1200 Ohm
20 dBu / 14 dBu / 8 dBu / 2 dBu
> 104 dB, 20 Hz to 20 kHz
<-98 dB (0.0013 %) @ 1 kHz
+0/-0.3 dB, 20 Hz to 20 kHz
EN 55103-1 and EN 55103-2
FCC part 15, Class B, CISPR 22, Class B
IEC 65, EN 60065, UL6500 and CSA E60065
CSA FILE #LR108093
32° F to 122° F (0° C to 50° C)
-22° F to 167° F (-30° C to 70° C)
Max. 90 % non-condensing
In/Out/Thru: 5 Pin DIN
1/4" phone jack
24x 2 character LCD
11.2" x 3.5" x x 10.25" (284 x89 x 267 mm)
4.1 lb. (1.85 kg)
100 to 240 VAC, 50 to 60 Hz (auto-select)
<15 W
1 year
Due to continuous development, these specifications
are subject to change without notice.
