(EN) Technical Specifications
TuningRange: A0(27.5Hz)-C8(4186Hz)
TuningAccuracy: +/-0.5cent
ReferencePitch: A4=435to445Hz(1Hzsteps)
Input Impedance: 500 kOhm (pedal on)
PowerSupply: One9VtypebatteryorACadapter(9VDC),-soldseparately
CurrentDraw: 45-50mA(typicaluse)
Dimensions (WxDxH): 72 mm x 122 mm x 45 mm
Weight: 300g/10.6oz(incl.battery)
Included items: 2 pcs. 3M velcro for pedal board
attachment
Due to continuous
development, these
specifications are subject to
change without notice

TC Electronic PolyTune Specifications

General

Type	Polyphonic Tuner
Tuning Range	A0 (27.5 Hz) to C8 (4186 Hz)
Bypass Mode	True Bypass
Current Draw	45 mA
Display	LED
Tuning Modes	Chromatic, Polyphonic
Accuracy	±0.5 cent
Input	1/4" TS (unbalanced)
Output	1/4" TS (unbalanced)
Power Supply	9V DC
Weight	300 g
Input Impedance	1 MOhm
Output Impedance	100 Ohm
Reference Pitch	A4 = 435 to 445 Hz (1 Hz steps)
