9 QUINTESSENCE HARMONIZER User Manual
• The LED on your pedal should turn green. If your TC pedal has more than
one LED, the leftmost LED should turn green. This indicates that the pedal is
ready to receive the software update.
• Release the footswitch.
• Your TC pedal will now be recognized as an updatable device.
Applying the rmware update
• Quit all MIDI-related applications (e.g. your DAW) on your computer and
launch the rmware updater you have downloaded in step 1.
• In the rmware updater app, select your TC pedal from the drop-down list
under the “STEP 1” heading.
• When the “Update” button under the “STEP 2” heading turns green, click it.
• The updated rmware will now be transferred to your TC pedal. Wait for the
progress bar to reach 100%. When the update procedure is complete, the
pedal will automatically restart.
7. 2 Changing the battery
If you need to change the battery of your TC ELECTRONIC eect pedal, proceed
as follows:
• Unscrew the thumb-screw on the back of the pedal and detach
the backplate.
• Unmount the old battery and attach the new battery to the battery clip
making sure the polarity is correct.
• Remount the back-plate.
Notes regarding batteries
• Batteries must never be heated, taken apart or thrown into re or water.
• Only rechargeable batteries can be recharged.
• Remove the battery when the pedal is not being used for a longer period of
time to save battery life.
• Always dispose batteries according to local laws and regulations.
8. Links
Support resources
• TC ELECTRONIC Support: tcelectronic.com/support/
• TC ELECTRONIC – product software: tcelectronic.com/support/software/
• TC ELECTRONIC – all product manuals: tcelectronic.com/support/manuals/
• TC ELECTRONIC user forum: forum.tcelectronic.com/
TC ELECTRONIC on...
• the Web: tcelectronic.com/
• Facebook: facebook.com/tcelectronic
• Google Plus: plus.google.com/+tcelectronic/
• Twitter: twitter.com/tcelectronic
• YouTube: youtube.com/user/tcelectronic
9. Specications
Bypass mode True Bypass (default) /
Buered Bypass, switchable
Input connector 2 x ¼" TS, unbalanced, mono
Input impedance 1 MΩ
Output connector 2 x ¼" TS, unbalanced, mono
Output impedance 1MΩ
Output connector 2 Standard ¼” jacks – mono/TS with
automatic mono/stereo sensing
Output impedance 100Ω
Power input Standard 9 V DC, centre negative
>300 mA (power supply not included)
Battery Option 9 V (battery not included)
USB port Mini USB connector for rmware updates
Dimensions (H x W x D) 72 x 122 x 50 mm (2.8 x 4.8 x 2.0")
