TC FLUID CONTROL KMS-2 - Certification

KMS-2/Exia Transmitter
Installation and Operating Manual
ATEX
Rev D 20/09/2018 KMS-2/Exia IOM Page 11 of 13
Certification
Certificate No’s. Baseefa 06 ATEX 0159 X, IECEx BAS 06.0038 X
Explosion protection Type: Ex ia
Gas Group: IIC
ATEX Approval Type: II 1G Exia IIC T2 … T6 Ga or II 1G Exia IIB T2 … T6 Ga
Notified Body No. CE 1180
Input Parameters Conn1 Terminal + w.r.t -
Ui = 28V, Ii = 93mA, Pi = 0.65W, Ci = 0, Li = 30uH.
Temperature Class
The relationship between the temperature class and maximum process temperature for the ambient
temperature range is as shown in the following table.
Temperature Class Process Temperature Ambient Temperature Range
T2
≤ 250°C
-50°C
≤ Ta ≤ 60°C
T3
≤ 195°C
T4
≤ 130°C
T5
≤ 95°C
T6
≤ 80°C
-50°C
≤ Ta ≤ 40°C
Table 2
Relationship between Temperature class,
process temperature, and ambient temperature
In accordance to EN60079-11:2012 clause 6.3.13 this apparatus is capable of withstanding a 500V
isolation test.
EMC
In accordance to EU council directive 2014/30/EU
Emissions EN 61326:2004 (Class B)
STANDARD DESCRIPTION PORT RESULT
EN 61326 Radiated Emissions Enclosure Pass
EN 61326 Conducted Emissions Not applicable Not Tested
Immunity tests to EN 61326: 2004 A1, A2, A3
STANDARD DESCRIPTION PORT RESULT
61000-4-2 Electrostatic Discharge Enclosure Pass
61000-4-3 RF Electromagnetic Field Enclosure Pass
61000-4-4 EFT/ Burst DC Port Pass
61000-4-5 Surge DC Port Pass
61000-4-6 Conducted RF DC Port Pass
61000-4-8 Magnetic Field Enclosure Not Tested
61000-4-11 Voltage Dip/ interruptions Not applicable Not Tested
