TC-Helicon VoiceTone D1 User Manual

1 - Effect on/off footswitch
2 - Effect active LED indicator
3 - Doubling style selector
4 - MIC GAIN control for input level
5 - Balanced XLR mic input
6 - Balanced XLR mono output
7 - Power in
8 - USB connector to computer
9 - Input level LED; green=signal, red=clip
10 - Effect on/off via optional mic (MP-75): in=on
11 - Mix control with center notch
1
4
5 6 7 8
9
10
3
11
2

TC-Helicon VoiceTone D1 Specifications

General

Type	Vocal Effects Processor
Technology	Digital
Effects	Reverb, Delay, Pitch Correction
Controls	Mix
Inputs	1 x XLR
Outputs	XLR
Power Supply	9V DC
Weight	1.5 lbs
