Connecting
MIC jack-ConnectyourmichereusingabalancedXLRcable.
Phantom power is always on.
OUT jack-ConnecttoyourPAmixer,anotherVoiceTonepedal
or powered speaker.
Power in-Connectthesupplied12VDCpowersupply.
USB -ConnecttoacomputerrunningtheTC-Helicon
VoiceSupportapplicationforregistration,latestversionandtips.
• Turn down your PA when making all connections
• The latest version of VoiceSupport is available free from www.tc-helicon.com/voicesupport
• TheUSBconnectiondoesnotprovidepowertotheunit
