2. General Product Information
Features/Hardware
Description
Design
Dimensions: 164.54*75.24*7.74mm; Weight: 184g
System
TCL UI 3.0; Android 12
Processor
MediaTek Helio G37, 12nm; CPU: 4xA53 2.3GHz+4xA53 1.8GHz; GPU: IMG GE8320 680MHZ
Memory & Storage
4 GB RAM + 64 GB(T676H)/128GB(T676K) ROM; Support micro SD cards up to 1TB
Display
6.7'' (exactly 6.66'') FHD+, AMOLED, water drop notch
Rear Camera
50 MP main camera: AF, 1/2.76 ", 0.64μm, F1.85, field of view 74.4 °, 5P lens.
2MP macro camera: FF, 1/5 ", 1.75μm, F2.4, field of view 88.8 °, 3P lens.
2MP depth camera: FF, 1/5 ", 1.75μm, F2.4, field of view 85 °, 3P lens.
Front Camera
8 MP front camera: FF, 1/4 '', 1.12μm, F2.0, field of view 80.6 °, 4P lens
Battery
5010mAh (standard)
Connectivity
2G bands: GSM 850/900/1800/1900
3G bands: UMTS B1/2/5/8
4G bands: B1/3/5/7/8/20/28 /38/40/41
Wi-Fi Direct
Bluetooth 5.0, Type-C, NFC
Dual SIM model: 1 4FF Nano + 1 4FF Nano or 1 TF card
Single SIM card model: 1 4FF Nano SIM + 1 TF card
Sensors
GPS, A-GPS, Galileo, GLONASS
Accelerometer, E compass, proximity sensor, light sensor, fingerprint sensor.
Accessories
5V2A Charger, Type-C Cable, Quick Guide, SIM Card Pin, PSI

TCL 30 Specifications

General

Color name	Tech Black
Form factor	Bar
Product color	Black
Platform	Android
Operating system installed	Android 12
Talk time (3G)	- h
Battery capacity	5010 mAh
Battery recharge time	3 h
Panel type	AMOLED
Screen shape	Flat
Pixel density	395 ppi
Display diagonal	6.7 \
Touchscreen type	Capacitive
Display brightness	650 cd/m²
Display resolution	1080 x 2400 pixels
Native aspect ratio	20:9
Maximum refresh rate	60 Hz
Contrast ratio (typical)	100000:1
High Dynamic Range (HDR) supported	Yes
Refurbished	No
Graphics card	IMG GE8320
Processor cores	4
Processor model	Helio G37
Processor family	MediaTek
Processor frequency	2.3 GHz
Coprocessor frequency	1.8 GHz
Processor architecture	ARM Cortex-A53
Speakers	stereo
Audio formats supported	AAC, AAC+, AMR, APE, AWB, FLAC, MP3, PCM, Vorbis, eAAC+
Video formats supported	AVC, H.263, H.264, H.265, HEVC, MPEG4, VP8, VP9
RAM type	LPDDR4X
User memory	44 GB
RAM capacity	4 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	1000 GB
Internal storage capacity	64 GB
Rear camera type	Triple camera
Front camera type	Single camera
Video recording modes	1080p
Rear camera pixel size	0.64 µm
Front camera pixel size	1.12 µm
Rear camera sensor size	1/2.76 \
Front camera sensor size	1/4 \
Rear camera aperture number	1.85
Front camera aperture number	2
Second rear camera pixel size	1.75 µm
Second rear camera sensor size	1/5 \
Rear camera resolution (numeric)	50 MP
Front camera resolution (numeric)	8 MP
Macro camera resolution (numeric)	2 MP
Second rear camera aperture number	2.4
Rear camera field of view (FOV) angle	74.4 °
Front camera field of view (FOV) angle	78 °
Third rear camera field of view (FOV) angle	88.8 °
Second rear camera field of view (FOV) angle	85 °
Cables included	USB Type-C
4G standard	LTE
3G standards	HSPA+
SIM card type	NanoSIM
Bluetooth version	5.0
SIM card capability	Dual SIM
Mobile network generation	4G
Subscription type	No subscription
USB version	2.0
Headphone connectivity	3.5 mm

Weight and Dimensions

Depth	7.74 mm
Width	75.24 mm
Height	164.54 mm
Weight	184 g
