TCL 50C645 User Manual

18
Other Information
Troubleshooting
Most problems you encounter with your TV can be corrected by consulting the following troubleshooting list.
No picture, no sound
1. Check if the fuse or circuit breaker is working.
2. Plug another electrical device into the outlet to make
sure it is working or turned on.
3. Power plug is in a bad contact with the outlet.
4. Check the signal source.
No colour
1. Change the colour system.
2. Adjust the saturation.
3. Try another channel. Black-white program may be
received.
Remote control does not work
1. Change the batteries.
2. Batteries are not installed correctly.
3. Main power is not connected.
No picture, normal sound
1. Adjust the brightness and contrast.
2. Broadcasting failure may happen.
Normal picture, no sound
1. Press the button to increase volume.
2. Volume is set to mute, press the button to
restore sound.
3. Change the sound system.
4. Broadcasting failure may happen.
Unorderly ripples on the picture
It is usually caused by local interference, such as cars,
daylight lamps and hair driers. Adjust the antenna to
minimize the interference.
Snowy dots and interference
If the antenna is located in the fringe area of a television
signal where the signal is weak, the picture may be
marred by dots. When the signal is extremely weak, it
may be necessary to install a special antenna to improve
the reception.
1. Adjust the position and orientation of the indoor/
outdoor antenna.
2. Check the connection of antenna.
3. Fine tune the channel.
4. Try another channel. Broadcasting failure may
happen.
Ignition
Black spots or horizontal streaks appear, or the picture
utters or drifts. This is usually caused by interference
from car ignition system, neon lamps, electric drills, or
other electrical appliance.
Ghost
Ghosts are caused by the television signal following two
paths. One is the direct path, the other is reected from
tall buildings, hills, or other objects. Changing the
direction
or position of the antenna may improve the reception.
Radio frequency interference
This interference produces moving ripples or diagonal
streaks, and in some case, loss of contrast in the picture.
Find out and remove the radio interference source.
*To bring you better visual experience, please remove
all labels, if any, from TV front panel and screen before
use.
*Figures and illustrations in this User Manual are
provided for reference only and may dier from actual
product appearance. Product design and specications
may be changed without notice.

TCL 50C645 Specifications

General

USB recording	No
Processor cores	4
4K Ultra HD upscaling	Yes
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technology	TCL AiPQ 3.0 Engine
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial in	0
Common interface Plus (CI+) version	1.4
Programming period	8 day(s)
Browser supported	-
Response time	15 ms
Display diagonal	50 \
Display brightness	250 cd/m²
Display technology	QLED
Native refresh rate	60 Hz
LED backlighting type	Direct-LED
Display diagonal (metric)	126 cm
Motion interpolation technology	PPI (Picture Performance Index) 3100
Dynamic contrast ratio marketing name	Mega Contrast
Pallet height	1680 mm
Pallet net width	1300 mm
Pallet net length	800 mm
Pallet net weight	213440 g
Quantity per pallet	12 pc(s)
Master (outer) case width	1265 mm
Quantity per pallet layer	6 pc(s)
Master (outer) case height	770 mm
Master (outer) case length	126 mm
Master (outer) case weight	13620 g
Number of layers per pallet	2 pc(s)
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292519742
Maximum number of stacking cartons	3 pc(s)
Video apps	Amazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Operating system version	11.0
Operating system installed	Google TV
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Battery weight	15 g
Warranty period	2 year(s)
Country of origin	Poland
Battery technology	Alkaline
Product color	Black
Panel mounting interface	300 x 300 mm
Package depth	653 mm
Package weight	Weight of the packaged product in gram.
RMS rated power	20 W

Weight and Dimensions

Depth (with stand)	292 mm
Width (with stand)	1112 mm
Height (with stand)	700 mm
Weight (with stand)	10500 g
Depth (without stand)	81 mm
Height (without stand)	648 mm
Weight (without stand)	10320 g
