TCL 50C645 User Manual

6
Remote Control Functions
Most of your television's functions are available via the menus that appear on the screen. The remote control(s)
supplied with your set can be used to navigate through the menus and to congure all the general settings.
Notes:
1.Figures and illustrations in this operation manual are provided for reference only and may dier from actual product
appearance. 2.The remote control type may be changed without notice, please refer to the remote control attached
with your TV. 3.Certain function may not be available for some models.
Connections and Setup
Circular
D-Pad
OK
To switch the sound o󰀨 and back on.
Standby / quit standby.
Add an entity to Watchlist in Google TV mode, and
display the TV list in DTV mode or future functions.
Press the Assistant button on your remote to talk
to the Google Assistant.
(Available only in Google
TV mode and when the network connection works
normally.)
To display the dashboard menu.
Circular D-Pad
Navigation direction buttons (
Up/Down/Left/Right
).
OK
To conrm an entry or selection.
To return to the previous menu or quit an app.
To access the Google TV homepage.
To access Electronic Program Guide.
(only available
for digital channels.)
To select input source.
/
To control the volume.
P+/P -
To change channels.
To display and edit the quick settings panel.
To display the quick panel.
To pop up the virtual remote control keyboard when
available.
To open TCL home on screen.
To access Netix.
To access Stan.
To access Prime video.
To access Disney.
To access YouTube.
To access TCL Channel.
Google and Google TV are
trademarks of Google LLC.
Notes:
- Certain function may be accessed from the virtual remote control
keyboard only, please press button on the remote to display it and
operate accordingly.
- The App buttons may dier depending on the model. The App
button is used for accessing the corresponding App.
-
How to Use the Remote Control
a. Before using the Google Assistant button, you must nish pairing the remote with the TV rst.
b. This Google Assistant function is only available for content search from certain apps.
c. Set languages in the
(Settings) > System > Language
to your local language or o󰀩cial language to en-
hance voice search successfully.

TCL 50C645 Specifications

General

USB recording	No
Processor cores	4
4K Ultra HD upscaling	Yes
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technology	TCL AiPQ 3.0 Engine
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial in	0
Common interface Plus (CI+) version	1.4
Programming period	8 day(s)
Browser supported	-
Response time	15 ms
Display diagonal	50 \
Display brightness	250 cd/m²
Display technology	QLED
Native refresh rate	60 Hz
LED backlighting type	Direct-LED
Display diagonal (metric)	126 cm
Motion interpolation technology	PPI (Picture Performance Index) 3100
Dynamic contrast ratio marketing name	Mega Contrast
Pallet height	1680 mm
Pallet net width	1300 mm
Pallet net length	800 mm
Pallet net weight	213440 g
Quantity per pallet	12 pc(s)
Master (outer) case width	1265 mm
Quantity per pallet layer	6 pc(s)
Master (outer) case height	770 mm
Master (outer) case length	126 mm
Master (outer) case weight	13620 g
Number of layers per pallet	2 pc(s)
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292519742
Maximum number of stacking cartons	3 pc(s)
Video apps	Amazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Operating system version	11.0
Operating system installed	Google TV
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Battery weight	15 g
Warranty period	2 year(s)
Country of origin	Poland
Battery technology	Alkaline
Product color	Black
Panel mounting interface	300 x 300 mm
Package depth	653 mm
Package weight	Weight of the packaged product in gram.
RMS rated power	20 W

Weight and Dimensions

Depth (with stand)	292 mm
Width (with stand)	1112 mm
Height (with stand)	700 mm
Weight (with stand)	10500 g
Depth (without stand)	81 mm
Height (without stand)	648 mm
Weight (without stand)	10320 g
