TCL 55C815 User Manual

5
Introduction
Remote Control Functions
Most of your television's functions are available via the menus that appear on the screen. The remote control(s)
supplied with your set can be used to navigate through the menus and to congure all the general settings.
Note
:
1.Figures and illustrations in this operation manual are provided for reference only and may differ from actual product
appearance. 2.The remote control type may be changed without notice, please refer to the remote control attached
with your TV. 3.Certain function may not be available for some models, e.g. GUIDE/SUBTITLE functions are only
available under DTV source. And DTV is not available for certain model. 4. The Google Assistant is not available in
certain languages and countries.
-
Installing Batteries
1.
Push to open the back cover as illustrated.
2.
Insert two AAA batteries according to the
polarities marked on the battery case.
3.
Replace the back cover as illustrated.
To display the TV settings menu.
Standby / quit standby.
To access the Smart TV homepage.
To display the Option menu.
▲/▼/
◄
/
►
Navigation direction buttons. The ▲/▼ buttons are also used to
change channels in TV mode.
OK
To conrm an entry or selection. This button is also used to
display the channel list in TV mode.
To return to the previous menu or quit an app.
To select input source.
Press the Assistant button on your remote to talk to the Google
.. Assistant. (Available only when the network connection works
...normally.)
To pop up the virtual remote control keyboard when available.
To control the volume.
To change channels.
To access Netix.
(Not available for some models.)
To access TCL Channel.
RC802V remote control
Note:
Certain function may be accessed from the virtual remote control keyboard only,
please press button on the remote to display it and operate accordingly.
How to Use the Remote Control
When using the Google Assistant button for the rst time, you will be prompted to pair the remote with the TV.
a. Keep the remote control and TV in 1 meter, please follow the on-screen guide for pairing instructions. You can
use the Google Assistant button after activating successfully.
b. The Google Assistant is only available for content search from certain apps.
c. Set languages in the
Settings
to your local language or ofcial language to enhance voice search successfully.
Google and Android TV are trademarks of Google LLC.
1 2
3
/
P
/

TCL 55C815 Specifications

General

Screen shape	Flat
Response time	10 ms
Display diagonal	55 \
Display brightness	470 cd/m²
Display technology	QLED
Native aspect ratio	-
Native refresh rate	50 Hz
Peak luminance ratio	72 %
LED backlighting type	Edge-LED
Supported video modes	2160p
Viewable size diagonal	1390 mm
Display diagonal (metric)	139.7 cm
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	PPI (Picture Perfomance Index) 2800
Dynamic contrast ratio marketing name	Mega Contrast
RF connector type	F, IEC
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio Return Channel (ARC)	Yes
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Video apps	Amazon Prime Video, Netflix, YouTube
Smart modes	Game, Movie, Sports
Lifestyle apps	Google Apps
Operating system version	9.0
Operating system installed	Android
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HIN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWA, TUR, UKR
Audio decoders	DTS, Dolby Atmos, Dolby Digital, DTS-HD, Dolby Digital AC4, Dolby TrueHD
RMS rated power	35 W
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth profiles	A2DP, HID
AC input voltage	220 - 240 V
Energy efficiency scale	A to G
Power consumption (max)	180 W
Power consumption (standby)	0.28 W
Power consumption (typical)	112 W
Product color	Black
Mercury content	0 mg
Heavy metals free	Hg (mercury)
Panel mounting interface	400 x 200 mm
Processor cores	4
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG, PNG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPEG2, MPG, TS, VP9, WEBM, WMV
Picture processing technology	TCL IPQ 2.0 Engine
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Remote control type	RC602S6+RC802N4
Package depth	168 mm
Package width	1400 mm
Package height	875 mm
Package weight	23800 g
Battery type	AAA
Battery technology	Alkaline
Truck type	87 cbm
Pallet height	1870 mm
Pallet length	800 mm
Pallet weight	255400 g
Pallet net weight	15000 g
Quantity per truck	280 pc(s)
Quantity per pallet	10 pc(s)
Number of pallets per truck	28 pc(s)
Maximum number of stacking cartons	3 pc(s)

Weight and Dimensions

Depth (with stand)	295 mm
Height (with stand)	783.4 mm
Weight (with stand)	17800 g
Depth (without stand)	64 mm
Width (without stand)	1227.4 mm
Height (without stand)	739.7 mm
Weight (without stand)	17400 g
