6
Introduction
To switch the sound off and back on.
Standby / quit standby.
Numeric buttons
To enter channel numbers or a digit.
To access TCL Channel.
LIST
To display the channel list.
To control the volume.
To display programme information, if available.
To display the TV settings menu.
P /
To change channels.
To access the Smart TV homepage.
To display the Option menu.
▲/▼/
◄
/
► Navigation direction buttons.
OK
To conrm an entry or selection.
To return to the previous menu or quit an app.
To select input source.
EXIT
To exit the Settings menu.
LANG
To select an audio language available for selected
digital TV programme.
GUIDE
To toggle the Electronic Programme Guide on or off.
(only
available for digital channels
.
)
TEXT
To toggle Teletext on or off.
SUBT.
To select a subtitle language available for selected digital TV
programme.
Color buttons
To select tasks or Teletext pages.
To start fast reverse.
To pause playback.
To start fast forward.
To access the Record menu.
To start playback.
To stop playback.
To access Netix.
(Not available for some models.)
RC802N remote control
-
Installing Batteries
1.
Push to open the back cover as illustrated.
2.
Insert two AAA batteries according to the polarities marked on the battery case.
3.
Replace the back cover as illustrated.

Table of Contents

Other manuals for TCL 55C815

Preview: Manual
Manual5 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 55C815 and is the answer not in the manual?

TCL 55C815 Specifications

General IconGeneral
Screen shapeFlat
Response time10 ms
Display diagonal55 \
Display brightness470 cd/m²
Display technologyQLED
Native aspect ratio-
Native refresh rate50 Hz
Peak luminance ratio72 %
LED backlighting typeEdge-LED
Supported video modes2160p
Viewable size diagonal1390 mm
Display diagonal (metric)139.7 cm
Supported graphics resolutions3840 x 2160
Motion interpolation technologyPPI (Picture Perfomance Index) 2800
Dynamic contrast ratio marketing nameMega Contrast
RF connector typeF, IEC
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio Return Channel (ARC)Yes
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Video appsAmazon Prime Video, Netflix, YouTube
Smart modesGame, Movie, Sports
Lifestyle appsGoogle Apps
Operating system version9.0
Operating system installedAndroid
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HIN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWA, TUR, UKR
Audio decodersDTS, Dolby Atmos, Dolby Digital, DTS-HD, Dolby Digital AC4, Dolby TrueHD
RMS rated power35 W
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth profilesA2DP, HID
AC input voltage220 - 240 V
Energy efficiency scaleA to G
Power consumption (max)180 W
Power consumption (standby)0.28 W
Power consumption (typical)112 W
Product colorBlack
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface400 x 200 mm
Processor cores4
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG, PNG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPEG2, MPG, TS, VP9, WEBM, WMV
Picture processing technologyTCL IPQ 2.0 Engine
High Dynamic Range (HDR) technologyDolby Vision, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Remote control typeRC602S6+RC802N4
Package depth168 mm
Package width1400 mm
Package height875 mm
Package weight23800 g
Battery typeAAA
Battery technologyAlkaline
Truck type87 cbm
Pallet height1870 mm
Pallet length800 mm
Pallet weight255400 g
Pallet net weight15000 g
Quantity per truck280 pc(s)
Quantity per pallet10 pc(s)
Number of pallets per truck28 pc(s)
Maximum number of stacking cartons3 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)295 mm
Height (with stand)783.4 mm
Weight (with stand)17800 g
Depth (without stand)64 mm
Width (without stand)1227.4 mm
Height (without stand)739.7 mm
Weight (without stand)17400 g
