EN
11
English
Chapter 4 - Using more of your TV
Installing channels
This section describes how to search and store
channels automatically. This may be done in any of
the cases below:
- you have skipped the channel installation step in the
initial setup;
- you are prompted that there are no channels in TV
mode;
- you want to update your channels.
1. In TV mode, press
on the remote control
and select Settings > Channels and inputs >
Channel > Channel scan. Press OK/ to enter.
2. The TV installs and arranges channels according
to your country or region. Press / to select
Country/Region, and press OK/ to enter. Enter
the default password 1234 or your own password
in case you have changed the password in the
System > Lock menu. Press / to select your
country or region and press OK to conrm.
3. Press / to select Automatic search and press
OK to enter.
4. Press / to select Tuner mode and press
/ to select Cable, Antenna or Satellite.
(Note: Satellite option is available only in selected
models.)
5. Press / to select other options to congure.
6. After conguration is completed, press to select
Search and press OK to start scanning channels.
7. The channel search may take a few minutes. After
the automatic search, channels are arranged in a
preset order. If you want to edit the channel list,
press
on the remote control, select Settings
> Channels and inputs > Channel > Channel
organizer and press OK to enter.
Common interface
Encrypted digital TV channels can be decoded with a
common interface module and a card provided by a
digital TV service operator.
The common interface module may enable several
digital services, depending on the operator and
services you choose (for example, pay TV). Contact
your digital TV service operator for more information
about services and terms.
Using the common interface module
WARNING: Switch o󰀨 your TV before inserting a
common interface module. Be sure to follow the
instructions described below. Wrong insertion of
a common interface module may damage both the
module and your TV.
1. Following the directions printed on the common
interface module, gently insert the module into the
common interface slot on the TV.
2. Push the module in as far as it will go.
3. Turn on the TV and wait for the common interface
function to be activated. This may take several
minutes.
Note: Do not remove the common interface
module from the slot. Removing the module
will deactivate the digital services.
Accessing common interface services
After inserting and activating the common interface
module, press
on the remote control, select
Settings > Channels and inputs > Channel >
Common interface and press OK to enter.
This menu option is only available if the common
interface module is correctly inserted and activated.
On-screen applications and content are provided by
your digital TV service operator.
Using subtitles
You can enable subtitles for each TV channel.
Subtitles are broadcast via Teletext or DVB-T/DVB-C/
DVB-S/DVB-T2/DVB-S2 digital broadcasts. With
digital broadcasts, you have the additional option of
selecting a preferred subtitle language.
Turning on/o󰀨 subtitles
1. Press on the remote control, select Settings >
Channels and inputs > Channel > Subtitle and
press OK/► to enter.
2. Select the Subtitle option, and press OK to toggle
between on or o󰀨.
3. Press
to return to the previous menu.
Enabling subtitle languages on digital TV
channels
1. Press on the remote control, select Settings
> Channels and inputs > Channel > Subtitle >
Digital subtitle language 1st and press OK/► to
enter.
2. Press / to select a subtitle language as your
preferred language and press OK to conrm.
3. Press / to select Digital subtitle language
2nd and press OK/► to enter.
4. Press / to select a secondary subtitle language
and press OK to conrm.
5. Press
to return to the previous menu.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 55C835 and is the answer not in the manual?

TCL 55C835 Specifications

General IconGeneral
Screen shapeFlat
Response time5.7 ms
Display diagonal55 \
Progressive scanYes
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display brightness500 cd/m²
Display technologyQLED
Native aspect ratio16:9
Native refresh rate120 Hz
LED backlighting typeMini LED
Display diagonal (metric)139.7 cm
Supported graphics resolutions3840 x 2160
Motion interpolation technologyPPI (Picture Performance Index) 4200
Dynamic contrast ratio marketing nameMega Contrast
Package typeBox
Package depth147 mm
Package width1391 mm
Package height858 mm
Package volume175441.266 cm³
Package weight23120 g
Product colorBlack
Ambient lightingNo
Panel mounting interface300 x 300 mm
Cables includedAC
Remote control typeRC902V1+RC802NU1
AC input voltage100 - 240 V
Power consumption (standby)0.227 W
Power consumption (typical)- W
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Music appsDeezer, Spotify, TIDAL, TuneIn, YouTube Music
Video appsAmazon Prime Video, Apple TV, BBC iPlayer, Disney+, Google TV, HBO, Netflix, Twitch, Vimeo, YouTube
Smart modesDolby Vision Bright, Dolby Vision Dark, Dynamic, Energy saving, IMAX Enhanced, Movie, Sports, Store
Lifestyle appsGoogle Apps
Operating system version11
App distribution platformGoogle Play
Operating system installedGoogle TV
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Audio decodersDolby Atmos, Dolby Digital AC4, Dolby TrueHD
RMS rated power20 W
Number of speakers2
Equalizer bands quantity7
Game featuresAuto Low Latency Mode (ALLM), Game Bar, Game Master, Game Master Pro, Variable Refresh Rate (VRR)
Processor cores4
AMD FreeSync typeFreeSync Premium Pro
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG, PNG
Video formats supportedH.264, VP9, WEBM, H.265, WMV, AVI, MPG, TS, MKV, MP4
Video compression formatsAVI, MKV, MP4, MPG, VP9, WEBM, WMV
Picture processing technologyTCL AiPQ 2.0 Engine
High Dynamic Range (HDR) technologyDolby Vision, Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Battery weight15 g
Country of originPoland
Battery technologyAlkaline
Google applicationsGoogle Chat
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth version5.2
Browser supported-
Bluetooth profilesSBC
RF input1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Truck type87 cbm
Pallet length1400 mm
Pallet net height1856 mm
Pallet net length800 mm
Pallet net weight246200 g
Quantity per truck280 pc(s)
Quantity per pallet10 pc(s)
Quantity per pallet layer5 pc(s)
Harmonized System (HS) code85287280
Number of layers per pallet2 pc(s)
Number of pallets per truck28 pc(s)
Quantity per master (outer) case1 pc(s)
Master (outer) case GTIN (EAN/UPC)5901292517380
Maximum number of stacking cartons3 pc(s)
Repairability index6.8
Digital Living Network Alliance (DLNA) specificationDMP
Weight and Dimensions IconWeight and Dimensions
Stand depth295 mm
Depth (with stand)280 mm
Height (with stand)790 mm
Weight (with stand)19000 g
Depth (without stand)68 mm
Width (without stand)1222 mm
Height (without stand)712 mm
Weight (without stand)16920 g
