TCL 55C835 User Manual

EN
14
English
Using more of your TV
When the TV is in networked standby mode, you can
use the App to wake up the TV remotely.
Notes:
- This feature is disabled if you press and hold the
button on the remote control and conrm to
shut the TV down.
- Before using the feature of networked waking up,
make sure the Quick start function is enabled.
- This function may not be available for certain
models.
- This feature is only available in Google TV mode.
Reset to factory default settings
Allows you to reset the TV to factory default settings.
1. Press
on the remote control, select Settings
> System > About > Reset > Factory reset >
Delete everything and press OK to conrm.
2. Use the numeric buttons on the remote control to
enter the password 1234 or your own password in
case you have changed it.
3. Select OK and press OK to conrm.
4. The Welcome screen appears. Follow the
instructions in the section Initial setup.
Using the hands-free TV voice control
Before using the hands-free TV voice control, connect
the TV to the network and make sure it can access
the Google website rst. Then follow the steps below
to access.
1. Turn the built-in MIC switch (Please refer to the
Quick Start Guide to nd the MIC switch on your
TV set) to on before using this function.
2. Press
on the remote control and follow the on-
screen guide to nish pairing the remote control
with the TV.
3. Select "Yes, I'm in".
4. Say "OK Google" or "Hey Google" to activate it.
Notes:
- This hands-free TV voice control is only available
for selected models. For details, please refer to
your local dealer.
- A quiet surrounding is required for better function
when using it. The recommended distance for
using the hands-free TV voice control is within 2
meters in front of it.
- Turn the built-in MIC switch to o if you are not
going to use it.
- The availability of hands-free TV voice control
depends on your region/country/language.
- Turn on both Quick start and Screenless
service in the Settings > System > Power and
energy menu to enjoy hands-free voice control
in TV standby mode.
- Standby power consumption will increase
because the built-in MIC is always listening
when the Google Assistant or voice control with
the built-in MIC is enabled.
- This feature is only available in Google TV
mode.
Variable Refresh Rate
Variable Refresh Rate is a feature that will allow
smooth gaming and eliminate screen tearing. The
refresh rate can dynamically change to up to 144hz.
Under source of HDMI1, HDMI2, HDMI3 or
HDMI4(the number of HDMI socket on the TV will
vary according to TV model), press
on the remote
control and select
Settings > Channels and inputs
> Inputs > Variable Refresh Rate
,
and press OK to
toggle between on or o󰀨.
Notes:
- 4K@144Hz is only available on HDMI 1 (not
available in all models). PC Graphics card must
be able to output 144Hz, please check your
graphics card specications.
- 4K@120Hz is only available on HDMI 1 or HDMI
2.
- some models support refresh rate up to 120Hz.
- You need to make sure your Games Console or
PC support Variable Refresh Rate, and you may
need to check your games console settings to
activate the function.
- The game/content also will need to support
Variable Refresh Rate, and you may also need
to check the settings within the game.
Apple AirPlay and HomeKit
Wirelessly share content with your TV using AirPlay
and control your TV using the Home app on your
iPhone, iPad, or Mac. You can set up AirPlay and
HomeKit at any time in Settings menu.
The function is enabled by default. To use the
function, make sure your iPhone, iPad, or Mac is iOS
or iPadOS device and the WiFi on the iOS or iPadOS
device is turned on. Then follow the steps below to
operate.
1. Press
on the remote control, select Settings
> System > AirPlay and HomeKit Settings and
press OK to enter, or press or (if available)
on the remote control, then select Inputs >
AirPlay > AirPlay and HomeKit Settings and
press OK to enter.
2. Press ▲/▼ to select the desired item and press
OK to enter the corresponding submenu.

TCL 55C835 Specifications

General

Screen shape	Flat
Response time	5.7 ms
Display diagonal	55 \
Progressive scan	Yes
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	500 cd/m²
Display technology	QLED
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Mini LED
Display diagonal (metric)	139.7 cm
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	PPI (Picture Performance Index) 4200
Dynamic contrast ratio marketing name	Mega Contrast
Package type	Box
Package depth	147 mm
Package width	1391 mm
Package height	858 mm
Package volume	175441.266 cm³
Package weight	23120 g
Product color	Black
Ambient lighting	No
Panel mounting interface	300 x 300 mm
Cables included	AC
Remote control type	RC902V1+RC802NU1
AC input voltage	100 - 240 V
Power consumption (standby)	0.227 W
Power consumption (typical)	- W
Programming period	8 day(s)
Number of OSD languages	29
Firmware upgradeable via	Auto upgrade wizard, Network, USB
Music apps	Deezer, Spotify, TIDAL, TuneIn, YouTube Music
Video apps	Amazon Prime Video, Apple TV, BBC iPlayer, Disney+, Google TV, HBO, Netflix, Twitch, Vimeo, YouTube
Smart modes	Dolby Vision Bright, Dolby Vision Dark, Dynamic, Energy saving, IMAX Enhanced, Movie, Sports, Store
Lifestyle apps	Google Apps
Operating system version	11
App distribution platform	Google Play
Operating system installed	Google TV
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.2
Audio decoders	Dolby Atmos, Dolby Digital AC4, Dolby TrueHD
RMS rated power	20 W
Number of speakers	2
Equalizer bands quantity	7
Game features	Auto Low Latency Mode (ALLM), Game Bar, Game Master, Game Master Pro, Variable Refresh Rate (VRR)
Processor cores	4
AMD FreeSync type	FreeSync Premium Pro
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG, PNG
Video formats supported	H.264, VP9, WEBM, H.265, WMV, AVI, MPG, TS, MKV, MP4
Video compression formats	AVI, MKV, MP4, MPG, VP9, WEBM, WMV
Picture processing technology	TCL AiPQ 2.0 Engine
High Dynamic Range (HDR) technology	Dolby Vision, Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Battery weight	15 g
Country of origin	Poland
Battery technology	Alkaline
Google applications	Google Chat
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth version	5.2
Browser supported	-
Bluetooth profiles	SBC
RF input	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Truck type	87 cbm
Pallet length	1400 mm
Pallet net height	1856 mm
Pallet net length	800 mm
Pallet net weight	246200 g
Quantity per truck	280 pc(s)
Quantity per pallet	10 pc(s)
Quantity per pallet layer	5 pc(s)
Harmonized System (HS) code	85287280
Number of layers per pallet	2 pc(s)
Number of pallets per truck	28 pc(s)
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292517380
Maximum number of stacking cartons	3 pc(s)
Repairability index	6.8
Digital Living Network Alliance (DLNA) specification	DMP

Weight and Dimensions

Stand depth	295 mm
Depth (with stand)	280 mm
Height (with stand)	790 mm
Weight (with stand)	19000 g
Depth (without stand)	68 mm
Width (without stand)	1222 mm
Height (without stand)	712 mm
Weight (without stand)	16920 g
