TCL 55C835 User Manual

EN
8
English
Additional remote control
Installing batteries
1. Push to open the back cover as illustrated.
2. Insert two AAA batteries according to the polarities
marked on the battery case.
3. Replace the back cover as illustrated.
Getting started
To switch the sound o󰀨 and back on.
Standby / quit standby.
Numeric buttons To enter channel numbers or a digit.
To access TCL Channel.
LIST To display the channel list.
/
To control the volume.
To display programme information, if available.
To display the dashboard menu.
P
/
To change channels.
To access the Smart TV homepage.
To display the Quick Settings panel. Or to perform the
corresponding function as indicated on screen.
▲/▼/◄/► Navigation direction buttons.
OK To conrm an entry or selection.
To return to the previous menu or quit an App.
To select input source.
EXIT To exit the on-screen menu.
LANG To select an audio language available for selected digital TV
programme.
GUIDE To toggle the Electronic Programme Guide on or o󰀨 (only
available for digital channels).
TEXT To toggle Teletext on or o󰀨.
SUBT. To select a subtitle language available for selected digital TV
programme.
Colour buttons To select tasks or Teletext pages; to be used for HbbTV
function.
To start fast reverse.
To pause playback.
To start fast forward.
ZOOM To select the screen mode.
Note: You are recommended to use the full screen mode.
Do not use the display mode with black bars on both sides
of the picture (such as 4:3) for a long time; otherwise the TV
screen may be damaged permanently.
To start playback.
To stop playback.
NETFLIX 1. To access Netix if available.
CAUTION: Risk of re or explosion if the battery is replaced by an incorrect type.

TCL 55C835 Specifications

General

Screen shape	Flat
Response time	5.7 ms
Display diagonal	55 \
Progressive scan	Yes
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	500 cd/m²
Display technology	QLED
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Mini LED
Display diagonal (metric)	139.7 cm
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	PPI (Picture Performance Index) 4200
Dynamic contrast ratio marketing name	Mega Contrast
Package type	Box
Package depth	147 mm
Package width	1391 mm
Package height	858 mm
Package volume	175441.266 cm³
Package weight	23120 g
Product color	Black
Ambient lighting	No
Panel mounting interface	300 x 300 mm
Cables included	AC
Remote control type	RC902V1+RC802NU1
AC input voltage	100 - 240 V
Power consumption (standby)	0.227 W
Power consumption (typical)	- W
Programming period	8 day(s)
Number of OSD languages	29
Firmware upgradeable via	Auto upgrade wizard, Network, USB
Music apps	Deezer, Spotify, TIDAL, TuneIn, YouTube Music
Video apps	Amazon Prime Video, Apple TV, BBC iPlayer, Disney+, Google TV, HBO, Netflix, Twitch, Vimeo, YouTube
Smart modes	Dolby Vision Bright, Dolby Vision Dark, Dynamic, Energy saving, IMAX Enhanced, Movie, Sports, Store
Lifestyle apps	Google Apps
Operating system version	11
App distribution platform	Google Play
Operating system installed	Google TV
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.2
Audio decoders	Dolby Atmos, Dolby Digital AC4, Dolby TrueHD
RMS rated power	20 W
Number of speakers	2
Equalizer bands quantity	7
Game features	Auto Low Latency Mode (ALLM), Game Bar, Game Master, Game Master Pro, Variable Refresh Rate (VRR)
Processor cores	4
AMD FreeSync type	FreeSync Premium Pro
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG, PNG
Video formats supported	H.264, VP9, WEBM, H.265, WMV, AVI, MPG, TS, MKV, MP4
Video compression formats	AVI, MKV, MP4, MPG, VP9, WEBM, WMV
Picture processing technology	TCL AiPQ 2.0 Engine
High Dynamic Range (HDR) technology	Dolby Vision, Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Battery weight	15 g
Country of origin	Poland
Battery technology	Alkaline
Google applications	Google Chat
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Bluetooth version	5.2
Browser supported	-
Bluetooth profiles	SBC
RF input	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Truck type	87 cbm
Pallet length	1400 mm
Pallet net height	1856 mm
Pallet net length	800 mm
Pallet net weight	246200 g
Quantity per truck	280 pc(s)
Quantity per pallet	10 pc(s)
Quantity per pallet layer	5 pc(s)
Harmonized System (HS) code	85287280
Number of layers per pallet	2 pc(s)
Number of pallets per truck	28 pc(s)
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292517380
Maximum number of stacking cartons	3 pc(s)
Repairability index	6.8
Digital Living Network Alliance (DLNA) specification	DMP

Weight and Dimensions

Stand depth	295 mm
Depth (with stand)	280 mm
Height (with stand)	790 mm
Weight (with stand)	19000 g
Depth (without stand)	68 mm
Width (without stand)	1222 mm
Height (without stand)	712 mm
Weight (without stand)	16920 g
